Specifications
Brand Name :
Eachinled
Model Number :
P5.95
Certification :
Rohs UL CE
Place of Origin :
Shenzhen China
MOQ :
6 square meters
Price :
Negotiation
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
5000 Square meters Per Month
Delivery Time :
15 Days
Packaging Details :
Wooden Case and Flight Case/Road Case
Refresh rate: :
2500hz
Display Function :
Indoor Event Music Show
Weight of Cabinet :
8kg
LED Constitute :
SMD3528 Black LEDs
Driving Method: :
1/16 scan
IC :
MBI5124
Power Supply :
AC110-220V
Cabinet Material :
Die Casting AluminumAluminum
Brightness :
900-1200 nit per sqm
Operating Life: :
>460000hours
Description

P5.95 P6 large stadium stage outdoor Event Concert led display screen

a. Calibration: Pixel-by-pixel brightness and color calibration technique to keep uniform brightness and natural colors of LED display.

b. Monitoring: Proprietary control system can monitor the temperature, brightness, status information of LED display in real time.

c. Remote network control: Controlling and changing all display information, controlling the displays of several cities in one place to change the contents at any time.

d. Adjustable brightness: Adjusting screen brightness automatically according to environmental lighting based on sensitive control system, adjusting it manually or by programmable menu.

e. Large screen control: Controlling super large size display stably without any black screen, frame vibration or reducing.

f. High refresh rate, high gray scale and high contrast ratio: More realistic pictures optimize commercial advertisement value.

Technical Specification:

Part Number

I-P3.9

I-P4.81

I-P5.2

I-P5.95

Pixel Pitch

3.91mm

4.81mm

5.21mm

5.95mm

Pixel Density

65536dot/m2

43264dot/m2

36864dot/m2

28224dot/m2

Resolution

128x128dot

104x104dot

96x96dot

84x84dot

LED Configuration

SMD 2121

SMD 3528

Brightness

900-1200CD/m2

900-1200CD/m2

1500-2000CD/m2

1100-1400CD/m2

View Distance

>4m

>5m

>5m

>6m

Scanning Mode

1/16

1/13

1/8

1/8

Display Scale

16.7M

16.7M

16.7M

16.7M

Max.Power Consumption

600W/m²

600W/m²

500 W/m²

450 W/m²

Ave.Power Consumption

300 W/m²

300 W/m²

250 W/m²

225 W/m²

Refresh Frequency

≥2000HZ

≥2000HZ

≥2000HZ

≥2000HZ

Cabinet Size

500mmx500mmX80mm

Cabinet Weight

8kg

IP Rating

IP43

Viewing Angle (H/V)

140°/120°

Gray Scale

14-16bit

Brightness Adjustment

8 levels adjustable

Gamma Correction

-5.0~+5.0

Environmental

INDOOR

Control Mode

Synchronous display with control PC by DVI

Support Input

Composite,S-Video,Component,VGA,DVI,HDMI,HD_SDI

Operation Power

AC100~240 50/60HZ

Operating Temperature

- 20℃~+50℃

Operating Humidity

10~95% RH

Operating Life

≥50,000hours

P5.95 P6 Large Stadium Stage Led Display Screen Outdoor Indoor Event Concert

FAQ

Q1: What's the pixel pitch for Indoor LED Display Screen ?

A1: Indoor&Outdoor 3.9mm/4.8MM/5.2MM/5.95)

Q2: Where is it used for?

A2: Indoor & Outdoor rental use. Widely used for backdrop of staging event, rental business, liveshow, concert, etc.

Q3: Can it play HD video?

A3: Yes, it can realize HD video function with Novastar controlling system.

Q4: What's the controlling system?

A4: Our standard controlling system for this model is Novastar. Also support other controlling system, like Linsn, etc.

Q5: How about the size of project?

A5: Please offer the size with "width by height" of project. We wil offer the suitable solution for your project size. I will appreciate it if any drawing files about installation offered.

Our Service and Mission

Eachinled has a perfect service system, including pre-sale service, in-sale service and after-sale service. To provide high quality service for our customers, we train every salesman with necessary product maintenance knowledge and organized a Technology Supporting Department with a group of excellent and professional engineers. Any problem you can contact us at any time you like.
Pre-sale service:
1. Reply enquiries in 24 hours.
2. Market research and forecast for customer.
3. Provide unique and professional solutions based on customer's requirement.
4. Data sheet and samples offer.
5. Other services, such as special packing design, factory visiting and so on.

In-sale service:
1. Tracking report in producing.
2. Quality test report for every order.
3. Photos and videos as per customer's requirement.
4. Free spare parts.

After-sale service:
1. Lifetime free maintenance and upgrade.
2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
3. Customer satisfaction tracking report.
4. Free technician training.
5. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on.
6. Special service for big project, such as stadium, exhibitions, squares and so on.
