Outdoor Ultra Slim LED Display 5.95mm LED Screen for Event and TV Show
Outdoor Ultra Slim LED Display 5.95mm LED Screen for Event and TV Show
Outdoor Ultra Slim LED Display 5.95mm LED Screen for Event and TV Show
Outdoor Ultra Slim LED Display 5.95mm LED Screen for Event and TV Show
Outdoor Ultra Slim LED Display 5.95mm LED Screen for Event and TV Show
Outdoor Ultra Slim LED Display 5.95mm LED Screen for Event and TV Show
Outdoor Ultra Slim LED Display 5.95mm LED Screen for Event and TV Show
Outdoor Ultra Slim LED Display 5.95mm LED Screen for Event and TV Show
Specifications
Brand Name :
Eachinled Optoelectronics
Model Number :
P5.95
Certification :
CE Rohs
Place of Origin :
Shenzhen China
MOQ :
6 square meters
Price :
Negotiation
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
5000 Square meters Per Month
Delivery Time :
15 Days
Packaging Details :
Wooden Case and Flight Case/Road Case
Gray Scale :
12bit
Display Function :
High Brightness Video Dislay Outdoor
Weight of Cabinet :
12kg
LED Constitute :
2000:!
Driving Method: :
1/18 scan
LED encapsulation :
SMD3535 high brightness
Control system :
Linsn Or Novastar
Cabinet Material :
Die Casting Aluminum
Brightness :
6200cd per sqm
LED refrsh rate :
2000hz
Description

Outdoor Ultra Slim LED Display 5.95mm LED Screen for Event and TV Show

v SMD3535 adopted ensures the brilliant color uniformity, high brightness and image sharpness.

v Water-proof signal and power jacks effectively prevent damage by splashed booze or beverage onto it.

v Aligning Pin makes it a really easy job to join all panels together into a seamless LED dancefloor screen.

v Outstanding durability of SMD LEDs and all components built inside the dancefloor display ensures long lifespan of more than 60,000 hours.

v Multi-video-formats (AVI, WMV, MOV, MPG, VOB, DAT, ASF, MP4) can be supported in the LED display system, many more formats (RMVB, RM, MPEG, MKV, FLV,3GP and etc) can be supported after codecs-pack are installed

Technical Specification:

Outdoor Die casting Aluminum 640mm Rental LED Displays

Module

Pitch/mm

P5.95

P8

P10

Module size/mm

250x250

320x320

320x320

Density of pixel/(dots/m2)

28,224

15,625

10,000

Led encapsulation

SMD3535

SMD3535

SMD3535

Main

Optimum viewing distance

6m

8m

100m

View angle / °

140 H,120 V

140 H,120 V

140H,120V

Max power consumption/W/M2

1100

1000

1000

Size of cabinet/mm

500X500

640X640

640X640

Weight of cabinet/kg

7.5

12.5

12.5

Driving method

1/8 scan constant current

1/4 scan constant current

1/4 scan constant current

Refresh rate Hz/S

≥2000

≥2000

≥2000

Luminance of white balance

≥5000 nits

≥6000 nits

≥5500 nits

Operation of Environmental Temperature/°C

below 30 to above 50

Working vlotage

110-220 VAC/+/- 10%

Grey scale/color

14-16bit

Input signal

RF,S-Video,RGB,RGBH,YUV,YC&Composition ,etc

Control system

Nova(sending card,receiving cards and Hubs)

Items

Parameter

Pixel Pitch

PH7.8125mm(Outdoor)

PH8.925mm(Outdoor)

Module Resolution(W*H)

64(W)*128(H)

56(W)*112(H)

Pixel Configuration

1R1G1B(in 3 n 1)

LED Encapsulation

White SMD 3535

Pixel Density

16384 Pixel /m2

12544 Pixel /m2

Driving Method

1/4 Scan

Refresh Frequency

≥2880Hz

Driver IC

Special constant current IC with high refresh rate & high gray scale

Grey Scale

14Bit(depending on the system and IC configuration)

Cabinet Size

500*1000mm

White balance

Brightness Driving Method

≥5500cd/ m2

Color Temperature

8000K±500(adjustable)

Viewing Angle

Horizontal 130°Vertical100°

Optimal Viewing Distance

>8m

>9m

Working Voltage

AC 220V/110V±10%

Module voltage

DC4.2V

Max Power Consumption

250W/PCS

280W/PCS

Avg.Power Consumption

130W/PCS

140W/PCS

Lifetime

50000 hours

Operating Temperature

–10℃ ~ 65℃

Net weight

13Kg/ pcs

13Kg/ pcs

Outdoor Ultra Slim LED Display 5.95mm LED Screen for Event and TV Show

FAQ

Q1: What's the pixel pitch for Indoor LED Display Screen ?

A1: Indoor&Outdoor (5.9mm /P6.25mm/P7.8mm/P8.925mm/P10mm)

Q2: Where is it used for?

A2: Indoor & Outdoor rental use. Widely used for backdrop of staging event, rental business, liveshow, concert, etc.

Q3: Can it play HD video?

A3: Yes, it can realize HD video function with Novastar controlling system.

Q4: What's the controlling system?

A4: Our standard controlling system for this model is Novastar. Also support other controlling system, like Linsn, etc.

Q5: How about the size of project?

A5: Please offer the size with "width by height" of project. We wil offer the suitable solution for your project size. I will appreciate it if any drawing files about installation offered.
