Specifications
Brand Name :
LINGMAN
Model Number :
HAK36050
Place of Origin :
China
MOQ :
1
Price :
1400-1560
Supply Ability :
300sets/month
Delivery Time :
7days
Packaging Details :
wooden box
center height/mm :
50
number of tools/N :
8T
load-bearing(including disc)/kg :
25
max.tangential torque/N.m :
500
maximum off load moment/N.m :
6
proximity switch :
PNP
hydraulic working pressure/Mpa :
2.0
N.W./kg :
30
Description

HAK36 Hydraulic CNC Spinning Lathe Tool Turret 8 Tools CNC Lathe Turret Tool Holder

HAK36 Hydraulic CNC Spinning Lathe Tool Turret 8 Tools CNC Lathe Turret Tool Holder

CHARACTERISTICS
1.Equipped with conjugate cam for indexing driving tool-disc smoothly,with compact design,fast tool change and high durability.
2.To driving,indexing and clamping/unclamping tool-holder disk with hydraulic force,precisely and correctly,torque is larger and stable,suitable for heavy cutting.
3.Smart selection of nearby tools controlled via proximity switch and logic control circuit,no error of tool-disc change.

Turret model HAK36050 HAK36063 HAK36063A HAK36080 HAK36080A HAK36100 HAK36125 HAK36160
Item Unit
center height mm 50 63 63 80 80 100 125 160
load-bearing(including disc) kg 25 40 40 60 60 120 180 280
max.tangential torque N.m 500 1000 1200 2200 3200 5200 11000 18000
maximun off load moment N.m 6 10 10 15 15 40 60 120
indexing time Sec 0.5 0.6 0.6 0.6 0.6 0.8 0.8 1.2
total indexing time for 180° Sec 1.2 1.6 1.6 1.6 1.6 1.8/2.2/2.5 2.0/2.4/2.8 3.0/3.8
oil hydraulic motor type 32 50 50 50 80 100 100 200
solenoid valve operated valve
proximity switch PNP PNP PNP PNP PNP PNP PNP PNP
hydraulic working pressure Mpa 2.0 3.0 3.0 3.0 3.0 3.5 4.0 4.5
flow rate L/min 12 12 12 12 20 30 40 40
repeatability accuracy mm 0.002 0.002 0.002 0.002 0.002 0.002 0.002 0.002
N.W.(without tool disk) kg 30 40 55 55 95 125 155 250
Turret specifications and accessories
8T Disc size mm 180/190 228 228 240 270/320 300/330/380 420 480
10T Disc size mm 330 380 420
12T Disc size mm 330/340 380/410 440 520
O.D.tool mm 16/20 20 20 20 20/25 25 25/32 32/40
facing tool mm 16/20 20 20 20 20/25 25 25/32 32/40
boring tool mm 20 25 25 25 32/40 40 40/50 50
number of tools N 8T 8T 8T 8T 8T/10T/12T 8T/10T/12T 8T/10T/12T 8T/12T
