Wood And Paper Laser Marking Controller 1064nm Wavelength For Ipg Laser Source
Wood And Paper Laser Marking Controller 1064nm Wavelength For Ipg Laser Source
Wood And Paper Laser Marking Controller 1064nm Wavelength For Ipg Laser Source
Wood And Paper Laser Marking Controller 1064nm Wavelength For Ipg Laser Source
Wood And Paper Laser Marking Controller 1064nm Wavelength For Ipg Laser Source
Wood And Paper Laser Marking Controller 1064nm Wavelength For Ipg Laser Source
Wood And Paper Laser Marking Controller 1064nm Wavelength For Ipg Laser Source
Wood And Paper Laser Marking Controller 1064nm Wavelength For Ipg Laser Source
Specifications
Brand Name :
BJJCZ
Model Number :
BJJCZ-SZ-B-H1
Certification :
CE
Place of Origin :
CHINA
MOQ :
1 set
Price :
negotiated
Payment Terms :
T/T, Western Union
Supply Ability :
1000set
Delivery Time :
3-5 workdays
Packaging Details :
carton
name :
wood and paper laser marking controller 1064nm wavelength for ipg laser source
Control software :
EZCAD,JCZ-EZCAD,EZCARD V2.14 version
Application :
Laser Marking
Warranty :
1 Year
Laser wavelength :
1064nm
Description

Wood And Paper Laser Marking Controller 1064nm Wavelength For IPG Laser Source

Description:

CON3: DB9 flying standard interface
Pin. Name Description
1 IN8 Input port 8
2,6 IN9+,IN9- Input port 9 positive
3,7 BCODEP/ BCODEN Input port 9 negative
4,5 ACODEP/ACODEN Encoder input B+/B-
8 VCC +5V output
9 GND Ground

Quick Details

Place of Origin:

China

Brand Name:

BJJCZ

Model Number:

LMCV4-DIGIT

Product name:

digital laser control board

Application:

CO2 laser marking/engraving

Wavelength:

10600/1064nm

The signals that control scanhead are digital, therefore can be connected to the digital

scanhead directly. Because the protocols that every manufacturer used are not always the same,

you need to conform which protocol is used. We also provide a D/A converter in the package. The

digital signal converted by which can be connected to a analog scanhead.

Applications:

Model Co2
Connect Method USB2.0
Galvo control signal Can be directly connected to a universal digital galvao
Number of Input Ports 16 universal input ports
Number of Output Ports 14 way TTL/ OC
Remark Signal Cache content repeated engraving
Extended Axis Support for 2 extension axis
Flight Marking Support
Multi-head Carving Support
Software Second Development Support
Suitable Laser CO2 / YAG / UV Laser
Applicable Material Glass, Plastic, Wood, Rubber, Paper
Support Operating System XP WIN7 WIN8 WIN10 32/64 Bit System
Built-in Encryption Chip Support
Power Supply 5V 3A

Wood And Paper Laser Marking Controller 1064nm Wavelength For Ipg Laser SourceWood And Paper Laser Marking Controller 1064nm Wavelength For Ipg Laser Source
