Scanner Type | Galvo with XY2-100 |
Input Signal | 10 input |
Output Signal | 8 output |
Communication Interface | PCIE |
Operation System | Win 7/8/10 64bit |
Software | EZCAD3 |
Extended Axis | 4 Axis |
J16: galvanometer signal, DB15
J7: Laser control interface, DB25
J17: IO/Mark on the fly Universal IO port and flight marking
The front of the board is printed with the words "DLC2-PCIE_V2"
● Output FIBER laser control signal with DB25 socket
● The galvanometer control signal is a digital signal, which can be directly connected to the internationally accepted digital galvanometer.
The IO signal and flight marking signal of the DLC2-PCIE card are output by J17 (40-pin black simple cow plug) on the board, and the IO signal and the flight marking signal are connected to a DB37 pin plug through a 40-core cable. The DB37 pin plug is mounted in the extension bracket and the bracket is attached to the chassis of the computer. As shown below
Please read this section carefully before installing and using the DLC2-PCIE control card. If you have any questions about this document, please contact BJJCZ.
1. Safe operation steps
● Please observe all safety instructions for lasers (including but not limited to descriptions and lasers, galvanometers and related sections in this document)
● Turn on the laser power at any time after turning on the computer power and galvanometer power. Otherwise, it may cause damage due to an uncontrollable laser beam.
We recommend that you use a shutter to avoid damage from uncontrolled lasers.
