SCHOTT Automatic Low-Loss Material Optical Glass Cutting Machine with Speed ≤500mm/s
SCHOTT Automatic Low-Loss Material Optical Glass Cutting Machine with Speed ≤500mm/s
Specifications
Brand Name :
CKD
Model Number :
CC-GD6
Certification :
ISO / CE / FDI
Place of Origin :
China
MOQ :
1
Price :
Negotiated
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
50 Sets Per Month
Delivery Time :
15-30 Work days
Packaging Details :
Plywood Box
Name :
Automatic Glass Cutting Machine
Material :
SCHOTT/SCHOTT/CORNING/NEG
Power :
80W
Speed :
≤500mm/s
Accuracy :
±0.01mm
Chipping :
≤5μm
Description

Automatic New Type 80 Low-Loss Material Optical Glass Cutting Machine

Equipment description

The picosecond laser glass cutting machine is a high-quality cutting equipment that offers superior performance compared to traditional cutting methods including high efficiency, with cutting speeds of up to 500mm/s, which is several times faster than CNC machines. It can cut up to 19mm thick glass in a single pass, which is three times more than traditional cutting methods. It also produces smooth and even edges, with no micro-cracks, breakage, or fragments.

Our in-house developed laser processes can be adapted to the customer’s requirements . Also , throughput demands can be easily achieved with our customized production solutions .

The optimized material flow in our systems allows to produce small quantities just as efficiently as mass production lots . Low production costs per component are a result of our short machine set-up times .

Our systems are capable of processing all typical materials :

  • CORNING ( Gorilla )
  • Schott ( Xensation )
  • NEG ( Dinorex )
  • ASHAI ( Dragontrail )
  • Others

SCHOTT Automatic Low-Loss Material Optical Glass Cutting Machine with Speed ≤500mm/s

Technical Parameters

Device Name Infrared Picosecond Glass Cutting & Splitting Machine
(All-in-One)		 Dual-Table Glass Cutting Machine Single Table Glass Cutting Machine
Type HT-IPC- 6070CD/6090CD HT-IPC-4050D/6070D/6090D HT-IPC- 4050/6070/6090
Cutting laser source
Laser type Infrared Picosecond
Power 50W ( optional 10W , 20W , 30W , 60W , 80W , etc .)
Wave length 1064nm , Beam quality: M2<1.2
Pulse width <10PS; Pulse frequency :1Hz-1000kHz
Type of cooling water-cooling
Cutting Performance
Drive Motor XY linear motor + grating ruler , positioning accuracy <±2um , repetition accuracy < soil 1.5um , acceleration 1G , linear speed maximum 1000mm/s
Cutting speed 0-500mm/s
Cutting thickness Ultra white glass one knife <19mm , green plate glass two knives <19mm(according to product material , thickness , speed requirements to choose the required laser power and cutting head focal depth ; Material may affect the processing thickness thicker can take multi-tool cutting)
Minimum cutting edge breakage ≤5um
Cutting Accuracy ±0.01mm
X/Y cutting stroke 600*900*2 / 800*1000mm*2 400x500mm , 600x700mm , 600x900mm dual platform 400x500mm ,600x700mm ,600x900mm
Cutting laser source
Laser Type RFCO2
Power 150W / 250W / 350W
Wave length 10.6um
Type of cooling water-cooling
Voltage , size , weight
Voltage, power <8KW,AC220V <5KW,AC220V <4KW,AC220V
Size

L2150mm×W2080mm×H1960mm

L2550mm×W2080mm×H1960mm

L1700mm×W1700mm×H1960mm

L2150mm×W2080mm×H1960mm

L2550mm×W2080mm×H1960mm

L1600mm×W1700mm×H1960mm

L1700mm×W1700mm×H1960mm

L1900mm×W1700mm×H1960mm
Weight 3500KG / 40000KG 2000KG / 3500KG / 40000KG 2000KG / 2500KG / 3000KG

SCHOTT Automatic Low-Loss Material Optical Glass Cutting Machine with Speed ≤500mm/s

However, an industry-suitable cutting process for high-index glasses needs to address the following critical features:

  • Low cost per unit
  • Flexible choice of lot size and shape
  • High bending strength after singulation of glasses
  • Avoidance of edge damages and chipping
  • Avoidance of particle formation during processing
  • Low part tolerances
