40.6° Cross Belt Frame DOE Laser Module Positioning Projection Light
40.6° Cross Belt Frame DOE Laser Module Positioning Projection Light
40.6° Cross Belt Frame DOE Laser Module Positioning Projection Light
40.6° Cross Belt Frame DOE Laser Module Positioning Projection Light
40.6° Cross Belt Frame DOE Laser Module Positioning Projection Light
40.6° Cross Belt Frame DOE Laser Module Positioning Projection Light
40.6° Cross Belt Frame DOE Laser Module Positioning Projection Light
40.6° Cross Belt Frame DOE Laser Module Positioning Projection Light
40.6° Cross Belt Frame DOE Laser Module Positioning Projection Light
40.6° Cross Belt Frame DOE Laser Module Positioning Projection Light
Specifications
Brand Name :
xinland
Model Number :
DOE Laser Module
Certification :
CE
Place of Origin :
China
MOQ :
10pcs
Price :
Negotiated
Payment Terms :
T/T, L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
50000pcs per months
Delivery Time :
5-8 work days
Packaging Details :
1pc carton
Product Type :
DOE Laser Module
Lens Angle :
40.6°
Light Source :
Red 100mW/Green 50mW/Blue 100mW
Wavelength :
650nm/520nm/450nm
Description

40.6° Cross Belt Frame Laser Module Positioning Projection Light with Imported from Germany Grating Sheet Laser Diode

Light Spot 0.5 meters Details:

Lens angle: 40.6°
0.5m: Length (40.6°): 370mm
0.5m: Width (31.5°): 281mm
At 0.5m: Cross length (13°): 115mm
Wavelength, Output Power, Voltage and Size Customizable
Installation height 0 meters - 5 meters can be used

The intelligent driver board with imported IC can supply power in a wide range of 2.8-5.2V (other voltages can be customized)

The whole set includes: Laser head + bracket + 2.8-5.2V adjustable power supply

40.6° Cross Belt Frame DOE Laser Module Positioning Projection Light

Name Wavelength Output Power Voltage(V) Electric Current Size Other Parameters
40.6° with Crossed Point Rectangle Red Laser 650nm 100mw DC 2.8-5.2V <500mA Φ16x70mm Lens angle: 40.6°
Wavelength, Output Power, Voltage and Size Customizable
Installation height 0 meters - 5 meters can be used
40.6° with Crossed Point Rectangle Green Laser 520nm 50mw DC 2.8-5.2V <500mA Φ16x70mm
40.6° with Crossed Point Rectangle Blue Laser 450nm 100mw DC 2.8-5.2V <500mA Φ16x70mm

40.6° Cross Belt Frame DOE Laser Module Positioning Projection Light

40.6° Cross Belt Frame DOE Laser Module Positioning Projection Light

40.6° Cross Belt Frame DOE Laser Module Positioning Projection Light

Warranty:

we offer one year limited warranty for our products. Damage due to misuse, Ill treatment and unauthorized modifications will beyond our warranty.

Payment Method:

PayPal ( PayPal fee should be afforded at buyer's side), Bank Transfer, Western Union, and Money Gram.

Shipping Method:

DHL/FEDEX/UPS/EMS/TNT Express service; Post Service
