405nm-1550nm Low Power Collimated Single Mode Laser Diode For Car Lighting And Projection
405nm-1550nm Low Power Collimated Single Mode Laser Diode For Car Lighting And Projection
405nm-1550nm Low Power Collimated Single Mode Laser Diode For Car Lighting And Projection
405nm-1550nm Low Power Collimated Single Mode Laser Diode For Car Lighting And Projection
Specifications
Brand Name :
XINLAND
Model Number :
XLM-405-K~XLM-1550-K Single Mode Collimated Laser Diode
Certification :
CE
Place of Origin :
Xi'an Shaanxi China
MOQ :
100pcs
Price :
Negotiated
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
1000 Dozen/Dozens per Day
Delivery Time :
7 days
Packaging Details :
1pcs/polybag,10pcs/inner box,100pcs/ctn
Diode Type :
Collimated Laser Diode
Wavelength :
405nm-1550nm
Mode Type :
Single Mode
Beam Divergence :
≤1mrad
Description

Low Power Single Mode Collimated Laser Diode

Product Details​:

Type: Collimated Laser Diode

Wavelength: 405nm-1550nm

Mode Type: Single Mode

Diode Type: 405-520nm, 635nm 150mW, 650nm 100/150mW not Photodiodes

Beam Divergence: ≤1mrad

Product Specifications:

Wavelength Part Number Output Power Mode Type Photodiodes Beam Divergence
405nm XLM-405-K 150/200/250mW Single Mode × ≤1mrad
445nm XLM-445-K 50/80mW Single Mode × ≤1mrad
488nm XLM-488-K 40mW Single Mode × ≤1mrad
505nm XLM-505-K 50mW Single Mode × ≤1mrad
520nm XLM-520-K 50mW Single Mode × ≤1mrad
635nm XLM-635-K 10/40mW Single Mode √ ≤1mrad
XLM-635-K 150mW Single Mode × ≤1mrad
658nm XLM-650-K 40mW Single Mode √ ≤1mrad
XLM-650-K 100/150mW Single Mode × ≤1mrad
670nm XLM-670-K 10mW Single Mode √ ≤1mrad
685nm XLM-685-K 30/50mW Single Mode √ ≤1mrad
785nm XLM-785-K 15/50/80mW Single Mode √ ≤1mrad
808nm XLM-808-K 50/100mW Single Mode √ ≤1mrad
830nm XLM-830-K 150/200mW Single Mode √ ≤1mrad
850nm XLM-850-K 30/150mW Single Mode √ ≤1mrad
880nm XLM-880-K 5mW Single Mode √ ≤1mrad
905nm XLM-905-K 80mW Single Mode √ ≤1mrad
940nm XLM-940-K 150mW Single Mode √ ≤1mrad
980nm XLM-980-K 30/80mW Single Mode √ ≤1mrad
1064nm XLM-1064-K 40/100/150mW Single Mode √ ≤1mrad
1310nm XLM-1310-K 15/20mW Single Mode √ ≤1mrad
1550nm XLM-1550-K 10/15mW Single Mode √ ≤1mrad
Note: √:Yes, ○:Optional, ×:No.

Since the output light of the laser diode is highly divergent, collimating optical elements are required. The aspheric lens can correct spherical aberration well and is a commonly used optical element to collimate the incident light to a beam waist of 1-5 mm. Since the beam size and transmittance both depend on the lens used, choosing an appropriate aspheric lens is a basic requirement for collimating laser diodes.
