FANUC Horizontal Machining Centers High Speed Double Pallet MDH65S
FANUC Horizontal Machining Centers High Speed Double Pallet MDH65S
Specifications
Model Number :
MDH65S
Certification :
ISO certification
Place of Origin :
China
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
20 sets per month
Delivery Time :
60days
Packaging Details :
The wooden case，Tin trunk ,Other seaworthy packing
Product name :
MDH65S double pallets Horizontal Machining Center
Worktable size :
630×630 mm
No. of pallet :
2
Max.table load :
800kg
Distance from table surface to spindle center :
80-830mm
Distance from spindle nose to table :
150～950mm
X/Y/Z travel :
780/750/800 mm
L×W×H :
4891*3200*3125mm
Description

MDH65S China double pallets Horizontal Machining Center High Speed FANUC Machine

Detailed Images

Standard configurations Optional configurations
• Two-speed internal transmission spindle •BRT CNC turntable
• Screw hollow cooling system • Spray cooling
•Automatic tool change system •High pressure cooling unit
• Screw chip conveyor (both sides) • Spindle cooling device
•Automatic lubrication system (spindle) •Electrical cabinet thermostatic control device
• Rigid tapping • Lifting chip conveyor
•Electrical cabinet heat exchanger •Grating ruler
• Spindle cooling device •M30 automatic power-off device
•Closed protective cover
• RS-232 data transmission system

Main Technical Parameters

Product Model Unit MDH50 MDH50A MDH65S
Worktable size (L*W) mm 500X500 500X500 630X630
No.of Pallet 2 Single table 2
Table type IT Opt:BRT
Table indexing IT (1° X360°)
BRT (0.001° X360°)
Table indexing time S 1.7(90°)
Pallet changing time S 6 - 6
Max. table load Kg 800
X/Y/Z-axis travel mm 780/750/800
X/Y/Z Axis guide way type Linear roller guideway
Distance from table surface to spindle center mm 80-830
Distance from spindle nose to table mm 150-950
Rapid traverse of X/Y/Z axis m/min 54
Cutting feed rate 1-20000
Spindle taper No.50 (7:24)
Max spindle speed rpm 8000(Motor Spindle)
Opt:12000(Motor Spindle)
Opt:6000(Gear box)
Spindle motor power
(Continueous/30 min)		 kw 8000rpm:18.5/22
12000rpm:25/30
6000rpm:22/26
Tool magazine capacity T 40(Opt:60/80/120)
Tool shank type BT50
Max. tool length mm 500
Max. tool weight Kg 25
Max. tool diameter (w/oadjacenttools) mm Ø115(Ø270)
Tool changing time(T-T) 2
X/Y/Z axis positioning accuracy 0.008
X/Y/Z axis repeatability accuracy 0.005
CNC controller FANUC 3li
Machine dimensions(LXWXH) mm 4891X3200X3125 4190X3200X3125 4891X3200X3125
Machine weight Kg 15000 14000 15000

Packing&Shipping

FANUC Horizontal Machining Centers High Speed Double Pallet MDH65S
