Specifications
Place of Origin :
China
Brand Name :
smtcl
Model Number :
CAK4065
Certification :
CE ISO
Packaging Details :
Package suitable for long distance sea freight
Supply Ability :
50 Set/Sets per Month
Price :
Negotiable
MOQ :
1 Set
Delivery Time :
30-50 days
Product name :
CAK4065 flat bed china cnc lathe machine
Max. Length of Workpiece (mm) :
750
Max. Spindle Speed (r.p.m) :
2400
Max. Turned Length (mm) :
650
CNC Control System :
FANUC GSK SEMENS optional
Max. Swing Diameter (mm) :
400
Max turning dia over slider :
200mm
Chuck size :
250mm
Spindle bore :
53mm
turret type :
Vertical 4 station
Description

High Quality Servo Motor CAK4065 Flat Bed China Cnc Lathe Machine Price Cnc Machinery Supplier

Product Introduction

CAK40 Series

  • 33HZ high efficient servo motor, low energy consumption, big torque
  • The span of the guide rail is 324 mm, the depth of quenching layer is 2-3 mm, and the hardness of the guide rail is 52HRC.
  • The accuracy of tool holder is high (+0.008mm), X-axis fast moving is 6m/min, Z-axis fast moving is 12m/min.
  • T-shaped trough reinforced structure of tailstock increase stability
  • Large waterproof tank, the waterproof structure from plugging to sparse, increase the waterproof performance of the whole machine
Machine Parameters

Model Unit CAK3665 CAK4065 CAK4085
Max workpiece length mm 750 750 1000
Max turning length mm 650 650 850
Max. swing diameter over bed mm 400 400 400
Max. swing diameter over slide mm 180 200 200
Max. cutting diameter mm 360 400 400
Diameter of spindle bore mm 53 53 53
spindle nose A26 A16 A16
Spindle speed stepless stepless Stepless
Spindle speed range m/min 100-3000 100-2400 100-2400
Chuck diameter mm 200 250 250
Main motor power kW 5.5 5.5 5.5
Tailstock sleeve diameter mm 60
Tailstock sleeve travel mm 140
Standard tool holder form vertical 4 station vertical 4 station vertical 4 station
Size of tool shank 20×20 mm 20×20 mm 20×20 mm
Rapid speed (X/Z-axis) m/min 6/12 6/12 6/12
Machining accuracy IT6-IT7 IT6-IT7 IT6-IT7
Net/Gross weight of machine kg 1860 1860 1960
Packing box dimensions(L×W×H) mm 2350x1500x1580 2350x1500x1580 2470x1500x1580
