Specifications
Brand Name :
SMTCL
Model Number :
HTC40B
Certification :
CE ISO certification
Place of Origin :
CHINA
MOQ :
1
Payment Terms :
T/T, L/C,, Western Union
Supply Ability :
50 sets per month
Delivery Time :
45-60 days
Packaging Details :
The wooden case，Tin trunk ,Other seaworthy packing
Key word :
Slant Bed CNC Lathe
Maximum turning length :
970
Maximum turning diameter :
Φ400
Maximum swing over bed :
Φ600
Max swing over slide :
Φ350
Max. Spindle Speed (r.p.m) :
4000 r.p.m
Travel (X Axis)(mm) :
200
Travel (Z Axis)(mm) :
1050
Description

FANUC High Rigidity High Torque CNC Lathe HTC40B 45 Degree Integral Slant Bed CNC Lathe For Metal

Product Description:

HTC 40B series slant bed CNC lathe is mainly used for cutting of internal and external cylindrical surfaces, internal and external conical surfaces with arbitrary taper angle, complex rotary internal and external surfaces, and cylindrical and conical threads of shaft-type parts or disk-type parts, and it can be used for grooving, drilling, reaming, reaming, and boring processing.

Product Features:

1,High rigidity

Rigidity is raised by 50% through enlargement of bearing,increase of spindle span,shortening of belt pulley overhang and new sliding tailstock structure.

2,Large torque
Torque is increased by 38.4%
3,Enhanced specification
Standard configuration of A2-8 spindle is realized forthe specifications at the same price, cutting diameter isincreased to Ф 400mm, swing diameter is increased toФ 600mm, maximum load carrying capacity is increasedby 30%, and heavy cutting of single side is 6mm.
Product Details:

Integral high-rigidity spindle

The product adopts A2-8 spindle with increased spindle torque and enhanced bearing specification to provide more power and rigidity.

Overall tilting machine tool body

HTC40B adopts rib-shaped design of 45° overall body optimization, and brings better chip removal effectand higher rigidity.

Guide rail tailstock

Tailstock of HTC40B is configuredwith sliding guide rail integratedwith machine tool body,telescoping sleeve and manuallocking and features good rigidity

Servo tool post

The product adopts servomotor driving for indexing,features high accuracy andhigh reliability and is able tomeet the requirements onhigh performance and fasttool change requirement.

2-axis feeding

X-axis and Z-axis adopt servo motor for driving,and direct coupling with ball lead screwis realized through elastic shaft coupling,so that users obtaingood machining accuracy andstable machining performance.

Integrated spindle encoder

The special spindle encoder has cancelled synchronous belt drive mechanism sothat malfunction rate hasbeen effectively reduced.

Industry application:

1,Outer ball cage, inner ball cage, rotor shaft, differential housing,

2,Tooth shaft, camshaft, turbocharger rotor shaft, half shaft,
3,Plate roller, piston rod, cross shaft, steering shaft.
Product Paramenters:

Product Paramenters:

Items
Unit
HTC40B/500
HTC40B/1000
Maximum swing diameter over bed
mm
Φ600
Φ560
Maximun cutting length
mm
500
970
Maximum cutting diameter
mm
Φ400
Φ360
Maximum swing diameter on the slide
mm
Φ320
Φ350
Spindle nose
mm
A2-8
A2-8
Spindle hole diameter
mm
Φ80
Φ80
Diameter of maximum through bar
mm
Φ65
Φ65
Spindle speed range
r/min
50-3500
50-4000
Spindle maximum output torque
Nm
245
177
Main motor
KW
15/11
15/11
Chuck diameter
inch
10''
8''
X-axis fast moving speed
m/min
30
30
Z-axis fast moving speed
m/min
30
30
X-axis travel
mm
200
200
Z-axis travel
mm
550
1050
ailstock stroke
mm
100
100
Tailstock spindle taper taper
Mohs
5#
4#
Standard tool holder form
mm
Horizontal 8 station
Horizontal 8 station
External knife
mm
25×25
25×25
Boring bar diameter
mm
Φ40/Φ32/Φ25/Φ20
Φ40/Φ32/Φ25/Φ20
Weight capacity(Disk type)
kg
200
200
Weight capacity(Shaft parts)
kg
500
500
Machine weight
kg
4200
4650
Machine tool appearance
mm
2700×1900×2100
3570×1860×1850

OUR Service:

Ensure you receive a high quality machine
1. Every parts need be inspected
2. Over 100 production process control
3. Over 200 inspection items
4. Sample processing of each machine
5. 72 hours trial run before delivery

Why Choose Us:
◆ Top quality sense, customers' requests come first
◆ 30 years + R & D history, the company was founded in 1993
◆ High-tech manufacturer with research anddesign capacity
◆ Stable and mature supplying system
◆ Young active sales and engineers for instant services(24 hours online)
◆ Upgrading on mechanism according to ergonomics and easy maintenance
◆ Our structure design principle: easy maintenance & installation, low cost maintenance, not affect production
About Us:
FANUC High Rigidity High Torque CNC Lathe HTC40B 45 Degree Integral Slant Bed CNC Lathe For Metal
Welcome to visit us!
Shanghai HD M&E Tech Co., Ltd is located in Shanghai, China. We specialize in CNC lathe, vertical machining center, horizontal machining center, gantry machining center, five-axis machining center, turn-milling center and various other CNC equipment. We have more than 200 kinds of machine tools. The quality and technology of products have reached the international advanced level.
Our factory has over 80 years’ history of manufacturing machine tools. The first lathe, drilling machine and boring machine were all born here. They have been one of the leader of China's Machine Tool industry and the largest machine tool manufacture in China. Machine tool products cover automobiles, aviation, new energy, construction machinery, ships, pump valves, bearings, 3C electronics, molds and other industries. We take the mission of providing the machine tools with leading technology, high quality and good service to our customers all over the world!
Our Factory:
FANUC High Rigidity High Torque CNC Lathe HTC40B 45 Degree Integral Slant Bed CNC Lathe For Metal

FAQ:

Q1. Are you a trade company or manufacturing company?

We are a manufacturing company.
Q2. What's your main products of your company?
We specialized in all kinds of machines, such as CNC Lathe, CNC Milling Machine, Vertical Machining Center,Conventional Lathe, Drilling Machine, Radial Drilling Machine, and so on.
Q3. Can you provide customized machine or SPM (Special purpose machine)?
Yes, we provide Smart CNC solutions for our customer in order to increase efficiency.
Q4: What's your warranty terms?
We will supply a replacement for parts that prove to be defective for a period of 12 months,
starting on the machine's bill of lading date.
Q5. What is the services?
Pr-sales:Customized solutions, planning and design;One-to-one service
After sales:7 days 24 hours on line service, Remote guidance of installation, docking with customer software system
Q6: Why choose your company?
Products from the development, design, manufacture, assembly of the entire production process are
carried out between plants with a complete production chain which is your most reliable guarantee.
Q7: Can your company send the technical personnel to our company and direct our workers overseas?
We can supply this kind of service. When the machines arrive the buyer's installation site, we can timely send mechanical and electrical engineers to install according to the buyer's schedule. All these can be quoted and list in the contract. The seller will cooperate with the buyer to deal with visa and installation preparation before going abroad.
Q8: What's the Payment Terms?
T/T 30% initial payment when order, 70% balance payment before shipment. irrevocable letter ofcredit at sight
