300 Psi Water Transfer Tube With Circular Woven Polyester Jacket Customized Length
300 Psi Water Transfer Tube With Circular Woven Polyester Jacket Customized Length
Specifications
Brand Name :
ASOE
Model Number :
Backflex
Certification :
ISO, NSF 61
Place of Origin :
China
MOQ :
10cm
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
10000m per week
Delivery Time :
depends on your order quantity
Packaging Details :
Standard Export Package
Product Name :
Water Transfer Hose
Operating Temperature Range :
From -60° F to 176° F (-50° C to 80° C)
ID :
2inch - 8inch
Wall Thickness :
0.10inch - 0.17inch
Working Pressure :
200 - 300psi
Bursting Pressure :
600 -900psi
Description

300 Psi Water Transfer Tube With Circular Woven Polyester Jacket Customized Length

ID Wall Thickness Weight Working Bursting
Pressure Pressure
Inch mm Inch mm lbs/ft kg/m PSI bar PSI bar
2 52+1.5 0.1 2.4 0.35 0.52 300 21 900 63
3 77+2.0 0.1 2.5 0.61 0.9 250 17 750 51
4 104+2.0 0.13 3 0.89 1.33 250 17 750 51
6 155+2.5 0.15 3.8 1.6 2.38 200 14 600 42
8 204.3.0 0.17 4.3 2.17 3.23 200 14 600 42

300 Psi Water Transfer Tube With Circular Woven Polyester Jacket Customized Length
Inner tube and cover: Smooth TPE-P cover and tube.

Reinforcement: Circular woven polyester jacket
Operating Temperature Range: From -60° F to 176° F(-50° C to 80° C)
Standard Color: Blue, black, other colors available per request
Standard Length: 300ft/91.5m, 330ft/100m, 660ft/200m; other lengths available per request;
Couplings: Storz couplings, Camlocks etc.

300 Psi Water Transfer Tube With Circular Woven Polyester Jacket Customized Length

Extra abrasion resistance for rugged terrain and extreme conditions

Puncture resistant

Chemicals resistant

UV resistant

300 Psi Water Transfer Tube With Circular Woven Polyester Jacket Customized Length

Backflex is one type of through-the-weave TPE-P covered hose which is made of TPE-P materials approved according to NSF 61 standard.

Backflex hoses shall be made from 100% high tenacity virgin synthetic yarn circular woven and completely, totally embedded in the TPE-P compound, excellent protected against mechanical damage, forming a single homogenous construction without the use of any glues or adhesives of any type.

Backflex performs excellently in age-resistance. It is theoretically supposed to be used for 30-50 years.

Backflex is a press-flat hose and can keep round shape under the condition of no pressure.

Backflex hoses can be pressed flat and can be easily laid down and retrieved as layflat hoses.

300 Psi Water Transfer Tube With Circular Woven Polyester Jacket Customized Length

Long Distance Fresh Water Transfer

Mining Dewater Soluiongs

Flowback Water Transfer Solutions
Pipe rehabilitation
By-pass Water Transfer Solution etc.

Long Distance Fresh Water Transfer Hose TPE-P material Black Color NSF 61 Standard

300 Psi Water Transfer Tube With Circular Woven Polyester Jacket Customized Length
