0.13inch 3.2mm WT Guillemin Couplings 300Psi nbr rubber hose
0.13inch 3.2mm WT Guillemin Couplings 300Psi nbr rubber hose
Specifications
Brand Name :
ASOE
Model Number :
Longman Fire
Certification :
ISO
Place of Origin :
China
MOQ :
10cm
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
10000m per week
Delivery Time :
depends on your order quantity
Packaging Details :
Standard Export Package
Product Name :
NBR layflat hose
Wall Thickness :
2.4 - 3.2mm(0.09 - 0.13inch)
Operating Temperature :
-37°C up to +95°C (-35°F up to 200°F) based on water
Standard Length :
15m, 20m, 30m, 50ft, 100ft; other lengths available per request
Standard Color :
yellow, red, other colors available per request
Cover :
ribbed with more abrasion resistance
Description

0.13inch 3.2mm WT Guillemin Couplings 300Psi nbr rubber hose

ID Wall Thickness Weigth Working Pressure Bursting Pressure
Inch mm Inch mm lbs/ft kg/m PSI Bar PSI Bar
1 1/2 38+1.5 0.09 2.4 0.32 0.48 250,300 17,21 750,900 51,63
1 3/4 45+1.5 0.09 2.4 0.36 0.54 250,300 17,21 750,900 51,63
2 51+1.5 0.1 2.6 0.4 0.6 250,300 17,21 750,900 51,63
2 1/2 64+1.5 0.1 2.6 0.55 0.82 250,300 17,21 750,900 51,63
3 76+2.0 0.11 2.8 0.66 0.98 250,300 17,21 750,900 51,63
4 104+2.0 0.12 3 0.9 1.34 250,300 17,21 750,900 51,63
5 127+2.0 0.13 3.2 1.09 1.62 225,250 16,17 675,750 48,51
6 155+2.5 0.13 3.2 1.4 2.09 225,250 16,17 675,750 48,51


0.13inch 3.2mm WT Guillemin Couplings 300Psi nbr rubber hose

Inner tube: Very smooth with minimum friction loss
Cover: ribbed with more abrasion resistance
Reinforcement: Circular woven polyester jacket
0.13inch 3.2mm WT Guillemin Couplings 300Psi nbr rubber hose

Inner tube: Very smooth with minimum friction loss
Cover: ribbed with more abrasion resistance
Reinforcement: Circular woven polyester jacket
Operating Temperature Range: -37°C up to +95°C (-35°F up to 200°F) based on water
Standard Color: yellow, red, other colors available per request
Standard Length: 15m, 20m, 30m, 50ft, 100ft; other lengths available per request;
Couplings: Aluminum or Brass NH/NST couplings, Aluminum or Brass Instantaneous Couplings, Storz, Guillemin Couplings, Gost Couplings etc.

0.13inch 3.2mm WT Guillemin Couplings 300Psi nbr rubber hose

Longman Fire is one type of through-the-weave hoses shall be made from 100% high tenacity synthetic Nitrile Rubber (NBR) covered fire hose.

Longman Fire yarn circular woven and completely, totally embedded in the NBR/PVC compound, excellent protected against mechanical damage, forming a single homogenous construction without the use of any glues or adhesives of any type.

NBR compound is composed of NBR and PVC. High percentage of NBR content contributes to better abrasion-resistance.

Small ID of Longman Fires are used as attack hoses. 4”, 5” and 6” Longman Fire hoses are used as supply line.

0.13inch 3.2mm WT Guillemin Couplings 300Psi nbr rubber hose
Suitable for military, fire brigades, marine and offshore installation, chemical industries, and refineries etc.

0.13inch 3.2mm WT Guillemin Couplings 300Psi nbr rubber hose
