10 - 17bar Nitrile Rubber Hose for Industrial Water Discharge, PVC/NBR through-the-weave hoses
10 - 17bar Nitrile Rubber Hose for Industrial Water Discharge, PVC/NBR through-the-weave hoses
Specifications
Brand Name :
ASOE
Model Number :
Wovenflex
Certification :
ISO
Place of Origin :
China
MOQ :
10cm
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
10000m per week
Delivery Time :
depends on your order quantity
Packaging Details :
Standard Export Package
Product Name :
NBR layflat hose
Standard Length :
50ft, 100ft, 20m, 30m
Standard Color :
Yellow, other colors available per request
Reinforcement :
Circular woven polyester jacket
Temperature range :
-40° to 150°F (-40° to 65°C)
Applications :
Water Discharge,Temporary installations (by-passes),Construction,Irrigation
Description

10 - 17bar Nitrile Rubber Hose for Industrial Water Discharge, PVC/NBR through-the-weave hoses

Nominal ID Wall thickness Weight Pressure rating
Inches mm Inches mm lbs/ft kg/m psi/bar
1 1/2" 38 0.09" 2.2 0.2 0.3 250psi/17bar, 200psi/14bar
2" 52 0.11" 2.7 0.33 0.49 250psi/17bar, 200psi/14bar
2 1/2" 64 0.12" 2.9 0.42 0.63 250psi/17bar, 200psi/14bar
3" 78 0.12" 3 0.48 0.72 250psi/17bar, 200psi/14bar
4" 104 0.13" 3.2 0.75 1.12 200psi/14bar, 150psi/10bar
6" 154 0.16" 3.9 1.5 2.24 200psi/14bar, 150psi/10bar
8" 205 0.17" 4.4 2.25 3.36 150psi/10bar
10" 255 0.18" 4.5 3 4.47 150psi/10bar
12" 305 0.18" 4.5 3.2 4.92 150psi/10bar

10 - 17bar Nitrile Rubber Hose for Industrial Water Discharge, PVC/NBR through-the-weave hoses

Wovenflex is one type of “through-the-weave” Heavy duty PVC/NBR lay flat hose.This hose features a unique one-piece,through-the-weave construction and attains its higher working pressure from a

synthetic woven polyester reinforcement than spiral plies;

its excellent durability is derived from a high-tensile PVC/NBR rubber compound,which completely encases the jacket.

10 - 17bar Nitrile Rubber Hose for Industrial Water Discharge, PVC/NBR through-the-weave hoses

• Water Discharge

• Temporary installations (by-passes)

• Construction

• Irrigation

10 - 17bar Nitrile Rubber Hose for Industrial Water Discharge, PVC/NBR through-the-weave hoses

Color:Yellow or Red
Temperature range:-40° to 150°F (-40° to 65°C)
Elongation at WP:<1.5%
Expansion at WP:<5%

Standard Length: 50ft, 100ft, 20m, 30m

Wovenflex, PVC/NBR through-the-weave hoses

This hose is designed for water discharge.


Construction: Circular polyester weave extruded internally and externally with PVC-NBR.

10 - 17bar Nitrile Rubber Hose for Industrial Water Discharge, PVC/NBR through-the-weave hoses
