Water Resistant PE Hose 100ft For Bypass Water Transfer Solution
Water Resistant PE Hose 100ft For Bypass Water Transfer Solution
Specifications
Brand Name :
ASOE
Model Number :
Backflex
Certification :
ISO, NSF 61
Place of Origin :
China
MOQ :
10cm
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
10000m per week
Delivery Time :
depends on your order quantity
Packaging Details :
Standard Export Package
Product Name :
Water Transfer Hose
Inner tube and cover :
Smooth TPE-P cover and tube
Reinforcement :
Circular woven polyester jacket
Operating Temperature Range :
From -60° F to 176° F (-50° C to 80° C)
Color :
Black or others
Coupling :
Storz couplings, Camlocks etc
Description

PE Hose designed for By-pass Water Transfer Solution Water Resistant 100ft

Product Application

Long Distance Fresh Water Transfer

Mining Dewater Soluiongs

Flowback Water Transfer Solutions
Pipe rehabilitation
By-pass Water Transfer Solution

Product Introduction

1.Backflex is one type of through-the-weave TPE-P covered hose which is made of TPE-P materials approved according to NSF 61 standard.

2.Backflex hoses shall be made from 100% high tenacity virgin synthetic yarn circular woven and completely, totally embedded in the TPE-P compound, excellent protected against mechanical damage, forming a single homogenous construction without the use of any glues or adhesives of any type.

3.Backflex performs excellently in age-resistance. It is theoretically supposed to be used for 30-50 years.

4.Backflex is a press-flat hose and can keep round shape under the condition of no pressure. Backflex hoses can be pressed flat and can be easily laid down and retrieved as layflat hoses.

♦ Extra abrasion resistance for rugged terrain and extreme conditions

♦ Puncture resistant

♦ Chemicals resistant

♦ UV resistant

Water Resistant PE Hose 100ft For Bypass Water Transfer Solution

Product Specification

Backflex™ TPE-P Layflat Flexible Pipe
ID
Wall Thickness
Weight
Working
Pressure
Bursting
Pressure
Inch
mm
Inch
mm
lbs/ft
kg/m
PSI
bar
PSI
bar
2
52+1.5
0.1
2.4
0.35
0.52
300
21
900
63
3
77+2.0
0.1
2.5
0.61
0.9
250
17
750
51
4
104+2.0
0.13
3
0.89
1.33
250
17
750
51
6
155+2.5
0.15
3.8
1.6
2.38
200
14
600
42
8
204.3.0
0.17
4.3
2.17
3.23
200
14
600
42

Product Features

Inner tube and cover: Smooth TPE-P cover and tube.
Reinforcement: Circular woven polyester jacket
Operating Temperature Range: From -60° F to 176° F(-50° C to 80° C)
Standard Color: Blue, black, other colors available per request
Standard Length: 300ft/91.5m, 330ft/100m, 660ft/200m; other lengths available per request;
Couplings: Storz couplings, Camlocks etc.
