Specifications
Description
PRODUCT PARAMETERS
Part name
 PC1250-8 Swing gearbox
Equipment Apply to KOMATSU EXCAVATOR
Part no. 21N-26-00110 21N-26-00120 21N-26-00140
NO.1 sun gear spline teeth 18 splines
Swing pinion shaft teeth 13 T
Item condition New
Logo LB
Gross weight --
MOQ 1 pc

Product Description

PC1250-8 SWING MACHINERY ASSEMBLY 21N-26-00110 21N-26-00120 21N-26-00140 21N2600110 21N2600120 21N2600140 PC1250-8 SWING GEARBOXPC1250-8 SWING MACHINERY ASSEMBLY 21N-26-00110 21N-26-00120 21N-26-00140 21N2600110 21N2600120 21N2600140 PC1250-8 SWING GEARBOXPC1250-8 SWING MACHINERY ASSEMBLY 21N-26-00110 21N-26-00120 21N-26-00140 21N2600110 21N2600120 21N2600140 PC1250-8 SWING GEARBOXPC1250-8 SWING MACHINERY ASSEMBLY 21N-26-00110 21N-26-00120 21N-26-00140 21N2600110 21N2600120 21N2600140 PC1250-8 SWING GEARBOXPC1250-8 SWING MACHINERY ASSEMBLY 21N-26-00110 21N-26-00120 21N-26-00140 21N2600110 21N2600120 21N2600140 PC1250-8 SWING GEARBOXPC1250-8 SWING MACHINERY ASSEMBLY 21N-26-00110 21N-26-00120 21N-26-00140 21N2600110 21N2600120 21N2600140 PC1250-8 SWING GEARBOX

Parts on group :

Pos. Part No Qty Parts name Comments

21N-26-00110 [1] Swing Machinery Assembly Komatsu 0.000 kg.

["SN: 30158-UP"] |$0.
1. 21N-26-33190 [1] Case Komatsu 172 kg.

["SN: 30158-UP"]
2. 07049-02430 [2] Plug Komatsu 0.003 kg.

["SN: 30158-UP"]
3. 06000-23124 [1] Bearing Komatsu 7.867 kg.

["SN: 30158-UP"]
4. 21N-26-31140 [1] Bearing Komatsu 33.1 kg.

["SN: 30158-UP"]
5. 21N-26-31110 [1] Shaft Komatsu 87 kg.

["SN: 30158-UP"]
6. 208-26-61291 [1] Seal, Oil Komatsu 0.5 kg.

["SN: 30158-UP"] analogs:["2082661290"]
7. 21N-26-33230 [1] Cover Komatsu China

["SN: 30158-UP"]
8. 01010-81030 [12] Bolt Komatsu OEM 0.03 kg.

["SN: 30158-UP"] analogs:["801015110", "M018011000306", "YM26116100302", "0101051030"]
9. 01643-31032 [12] Washer Komatsu 0.054 kg.

["SN: 30158-UP"] analogs:["802150510", "0164331030", "0164381032", "0164371032", "0164331022", "0164321032", "0164301032", "6127212530", "802170002", "R0164331032"]
10. 07000-15390 [1] O-ring Komatsu OEM 0.05 kg.

["SN: 30158-UP"]
11. 208-26-71181 [1] Carrier Komatsu 19 kg.

["SN: 30158-UP"] analogs:["2082671180"]
12. 208-26-71140 [4] Gear Komatsu 4.72 kg.

["SN: 30158-UP"]
13. 207-27-61230 [4] Bearing Komatsu 0.65 kg.

["SN: 30158-UP"]
14. 20Y-27-21250 [8] Washer, Thrust Komatsu China 0.03 kg.

["SN: 30158-UP"]
15. 207-27-61250 [4] Pin Komatsu China 1.75 kg.

["SN: 30158-UP"]
16. 20Y-27-21290 [4] Pin Komatsu OEM 0.03 kg.

["SN: 30158-UP"]
17. 208-26-71230 [1] Plate Komatsu China

["SN: 30158-UP"]
18. 205-32-51211 [1] Bolt Komatsu 0.17 kg.

["SN: 30158-UP"]
19. 208-26-71151 [1] Gear Komatsu China

["SN: 30158-UP"]
20. 01010-81645 [24] Bolt Komatsu China 0.104 kg.

["SN: 30158-UP"] analogs:["0101061645", "801015187", "0101031645", "0101051645", "37A0911184", "801014184"]
21. 01643-31645 [24] Washer Komatsu 0.072 kg.

["SN: 30158-UP"] analogs:["802170005", "0164301645"]
22. 208-26-71130 [1] Gear Komatsu 5.1 kg.

["SN: 30158-UP"]
23. 208-26-71241 [1] Plate Komatsu 0.06 kg.

["SN: 30158-UP"]
24. 208-26-71170 [1] Carrier Komatsu 7.65 kg.

["SN: 30158-UP"]
25. 207-26-71520 [3] Gear Komatsu 2 kg.

["SN: 30158-UP"]
26. 22U-26-21320 [3] Bearing Komatsu 1.1 kg.

["SN: 30158-UP"]
27. 22U-26-21240 [6] Washer Komatsu 0.6 kg.

["SN: 30158-UP"]
28. 207-26-71210 [3] Pin Komatsu 0.66 kg.

["SN: 30158-UP"]
29. 04064-04018 [6] Ring, Snap Komatsu 0.001 kg.

["SN: 30158-UP"] analogs:["802250040"]
30. 208-26-71210 [1] Holder Komatsu 0.42 kg.

["SN: 30158-UP"]
31. 04260-01270 [1] Ball Komatsu OEM 0.009 kg.

["SN: 30158-UP"]
32. 207-26-71510 [1] Gear Komatsu OEM 1.52 kg.

["SN: 30158-UP"]
33. 207-26-71261 [1] Plate Komatsu OEM 0.15 kg.

["SN: 30158-UP"]
34. 207-26-71610 [1] Cover Komatsu China

["SN: 30158-UP"]
35. 01010-81240 [10] Bolt Komatsu 0.052 kg.

["SN: 30158-UP"] analogs:["801015573", "0101051240"]
36. 01643-31232 [10] Washer Komatsu 0.027 kg.

["SN: 30158-UP"] analogs:["0164371232", "0164381232", "802170003", "R0164331232", "0614331232"]
37. 07042-30617 [2] Plug, Taper Komatsu China

["SN: 30158-UP"]
38. 07042-30108 [1] Plug Komatsu 0.008 kg.

["SN: 30158-UP"] analogs:["0704220108"]
