Large Size 86 inch Conference Room Interactive Touch Screen Flat Panel
Large Size 86 inch Conference Room Interactive Touch Screen Flat Panel
Large Size 86 inch Conference Room Interactive Touch Screen Flat Panel
Large Size 86 inch Conference Room Interactive Touch Screen Flat Panel
Specifications
Brand Name :
YODA
Model Number :
Y86AIO/TS-AP01
Certification :
ROHS,CE,FCC
Place of Origin :
Guangdong
MOQ :
1 PCS
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
5000PCS/per mouth
Delivery Time :
Within 7~15 days after order upon payment receiving
Packaging Details :
Plywood Case / Honeycomb Box / Flight Case
Size :
75inch
Response Time :
8ms
Brightness： :
350cd/m2
System： :
Android+Windows Dual System
Resolution： :
3840*2160P
Warranty :
1 Years
Description

Indoor 86inch large Conference Room Touch Screen Flat Panel 500W

Details of the product:

1. E-LED backlight, energy saving, high brightness, clear image.
2. Appearance is classic type, Stents shapes, Chassis or Other customized.
3. Support a variety of languages, such as English, German, Italian, Spanish and so on, you can choose according to your preferences.
4. With teleconference function, can support 20 people at the same time,And mobile phone terminal and computer terminal can be carried out.
5. Flat, light and thin, save a lot of raw materials and use space.

6. Low voltage applications, low drive voltage, solid use safety and reliability improvement.
7. Professional and humanized inner structure, wiring neatly.
8. 4mm tempered glass protection screen.

Display Information
Screen Size 55inch 65inch 75inch 86inch
Panel Type a-Si TFT-LCD a-Si TFT-LCD a-Si TFT-LCD a-Si TFT-LCD
Aspect Ratio 16:9 16:9 16:9 16:9
Resolution 3840*2160P 3840*2160P 3840*2160P 3840*2160P
Viewing Angle 89/89/89/89 89/89/89/89 89/89/89/89 89/89/89/89
Brightness 320cd/m2 350cd/m2 350cd/m2 350cd/m2
Active Area 1209.6x 680.4mm 1428.48x803.52mm 1649.664x927.936mm 1913x1084mm
Contrast Ratio 4000:1 4000:1 1200:1 1200:1
Response Time 8ms 8ms 8ms 8ms
Display Color 8 bit 1.67M 8 bit 1.67M 10 bit 1.07B 10 bit 1.07B
Field Frequency 60Hz 60Hz 60Hz 60Hz
Service Lifetime ≥60,000 hours ≥60,000 hours ≥60,000 hours ≥60,000 hours
Touch System
Sensing Type Infrared System (Multi 10 point touch)
Response Time 6ms
Connection Full-speed USB (Driver free)
Surface Protection Tempered Glass with 4mm thickness Standard
Graphic card Intel HD Graphics, Supports 1080P, H264, 3D play
Bluetooth Bluetooth4.0
Speaker 15W x2
Network WIFI/ RJ45
Port USB2.0*2/ USB3.0*2/ HDMI out*1/ VGA out*1/ RJ45 Lan port*1/ Speaker out*1/ Mic in*1
Built-in Dual System Android and Windows
Operating System Android 6.0
CPU Quad Core Cortex A7 1.8 GHZ
RAM DDR3 2G
ROM 32G
SD card slot Support MAX 128G
Port RJ45*1, VGA OUT*1, VGA IN*1, VGA AUDIO IN*1, Ypbpr IN*1, AV IN*2, AV OUT*1, Earphone*1, TV*1, Spdif OUT*1, HDMI IN*2, USB2.0*2, SD card slot*1, Touch USB*2, MIC*1
Languages English, French, Germany, Arabic, Italian, Japanese,Korean, Russian, Spanish, etc
Power
Power Supply 96~264V AC, 50/60Hz
Power Consumption 220W~500W
Operating Temperature 0℃~50℃
Storage Temperature -10℃~70℃
Supplied Accessories AC Power Cable, 4-in-1 Remote Control, Touch Pens*2, whiteboard software
Ambient Conditions
Dimension (L*W*H) 1290.5*817.6*99.3mm 1516.3*947.1*96mm 1737.7*1072.6*103mm 1991.1x1212.6x125.6mm
Package L*W*H 1427*963*232mm 1646*1062*230mm 1860*1230*260mm 2136*1370x280mm
Net weight 40KG 50KG 68KG 76KG

Real-picture of interactive flat panel

Large Size 86 inch Conference Room Interactive Touch Screen Flat Panel

Product's details

Large Size 86 inch Conference Room Interactive Touch Screen Flat Panel

Application


Large Size 86 inch Conference Room Interactive Touch Screen Flat Panel

FAQ

Q: What is your after-sale service?

A: We offer 100% guarantee on our product .

Q: When will you make the delivery?

A: We can make the delivery within 3-15 working days according to the size and quantities

of your order.

Q:What is the price? And do you provide customization, OEM or ODM service?

A:Our price is depend on the functions, sizes, designs, quantities, applications etc, please send the inquiry and tell us more about your requirements and project then enable us to quote the price accordingly. We have structure engineer teamwhich can provide customization,OEM or ODM service.

Q: If you are not online,how can i get contact with you?
A:if i am not online,please kindly check the following contact information,you can send me

email,you can call me or skype me,i will reply you ASAP.

Q: What's the shipment terms and delivery time of your company?
A:The goods can be shipped by courier,by air or by sea. Depend on quantity and

customer's requirement.

Q:When can I get the quotation?
A:We usually quote within 12 hours after we got your inquiry.
If it is very urgent,please call us or contact us via email,Skype or WhatsApp.

Q: What payment method you accept?

A: We accept TT or west union. And you can pay 30% deposit for production, and 70% balance before shipment.
