Android Interactive Digital Signage , 32 Inch Interactive Touchscreen Display
Android Interactive Digital Signage , 32 Inch Interactive Touchscreen Display
Specifications
Brand Name :
ADW
Model Number :
AD-32''-RK3288
Certification :
CE, ROHS, FCC, ISO9001
Place of Origin :
SHENZHEN, CHINA
MOQ :
1 piece
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
10000 PCS per Month
Delivery Time :
About 30-35 days for mass production
Packaging Details :
Carton / Wooden case
LCD Panel :
32''
Display interfaces :
LVDS, EDP
HD :
Support HDMI output
Touch screen :
10-point capacitive touch optional
resolution :
1920*1080
Product name :
Android Interactive Digital Signage with touch optional
LCD Type :
TFT
WIFI Module :
included (2.4G wifi / 5G wifi optional)
RJ45 :
10M/100/1000M Ethernet
USB :
Support USB host*2
Speaker output :
8 ohm 3W speaker
Input Voltage :
DC power 12V input
Application :
Indoor
Description

32 inch lcd display panel touch screen android interactive digital signage board media player with WIFI 4G Ethernet

List of Features
Easy setup and plug and play!
Auto Start when plug in the power adapter

Rooted Android OS

Non-Touch

WIFI, Bluetooth, optional LAN and 4G

USAGE:

Plug in the power adapter, and immediately the Android display will turn on

(no need to push a ON-OFF button).

You can hide the top and bottom bar in the Settings menu.

Install your software easily and let it play!

Specifications: (MotherBoard)

CPU Rockchip RK3288 Cortex-A17 Quad core GPU Mali-T764
Frequency 1.8 GHz
RAM LPDDR3 2G/4G optional
ROM EMMC 8GB/16G/32G/64G optional default: 8GB
Display interface LVDS (single way,6 bit dual-way, 8 bit dual-way), Resolution max 1920x1080, support 7"-84" display
EDP interface, Resolution max 4K
Screen voltage Support 3.3V/5V/12V(optional)
Touch Screen

I2C interface (support resistive touch, capacitive touch)

Support USB IR multi touch, sonic multi touch, optical multi touch
Network RJ45 interface, ethernet 10/100/1000M
Wi-Fi 802.11b/g/n, BT4.0
Support 4G LTE
Image rotation Support 0°, 90°, 180°, 270°, manual control or automatic, gravity (optional)
RTC Built in internal battery for Real time clock
interfaces Support MIPI camera, max 5MP
Support USB camera, max 2MP
HD out
6*USB HOST (Support USB camera @500w, USB printer, USB stick, mouse, keyboard, standard USB peripherals)
Serial ports x 3(1*UART+2*UART or RS232), support external devices (NFC module, printer, card reader etc.)
6*IO
TF card slot
D classamplifier,5W*2 8R
support microphone
Audio MP3, WMA, WAV, APE, FLAC, AAC, OGG, M4A,3GPP format
Video Support H.264, MPEG2, VP6, VP8, MVC, 2160P@24FPS decoding. on-line video such as YouTube, max support 4K,HTML5 playback,Flash10.1 playback
image Support JPG,BMP,PNG etc. picture formats, browse, orientation, slides, magnify
Power supply input:AC100-240V.50-60HZ, output: DC12V, 3A


Product Scenarios:

Android Interactive Digital Signage , 32 Inch Interactive Touchscreen Display

Android Interactive Digital Signage , 32 Inch Interactive Touchscreen Display

PACKAGING DETAILS
1, Packaging: film, foam and wooden case (international standard packaging), suitable for export.
2, Lead time: in 1 week for sample order, about 5 weeks for large order.

Android Interactive Digital Signage , 32 Inch Interactive Touchscreen Display

Pre-sale Service

Our professional team will serve on line for 24h for the customers.

If it is standard touch screen/ kiosk of our model, we will offer competitive price accordingly.
If clients have requirement of touch screen/ kiosk, our designing & sales team will provide professional advice on your respected project and will make every effort to make your project running.

After-sale Service

If any problems, you will get our reply within 24 hours. Solution will be offered instantly. We have professional technician to help solve any problem or direction during operating.

SHENZHEN SUNCHIP TECHNOLOGY CO., LTD is a leading company for integrating the whole industrial chain product, the main supplier for Digital Signage system & Embedded solution that focus on Rockchip chipsets solution and in-depth development, also deep customization of Android OS & Linux OS.

We have a professional 160+ employees’ team that including 100+ R&D engineers. We can provide one-stop service for Product definition, R&D of hardware & software, product schematic design, ID design, PCB layout, BOM scrubbing, High-quality order manufacturing, Good after-sales service and Diversified delivery modes for PCBA+Software, Customized software development, OEM&ODM products,

Our main products include Android ARM Board, Floor Standing Display, Wall Mounted Display, Stretched LCD Display, Open Frame Display and Android Media Player Advertising Box.
