High Resolution LCD Widescreen Monitor Stretched High Level Of Integration
High Resolution LCD Widescreen Monitor Stretched High Level Of Integration
Specifications
Brand Name :
ADW
Model Number :
AD-23.1ʺ-RK3128
Certification :
CE, ROHS, FCC
Place of Origin :
CHINA
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
10000 PCS per Month
Delivery Time :
About 30 days for large orders
Packaging Details :
Carton / Wooden case
LCD Panel :
23.1''
Product Type :
Android all in one advertising
CPU&GPU :
RK3128 Quad-core
Operating system :
Android 6.0
Resolution :
IPS 1920*158
RAM :
1GB/2GB (optional)
ROM :
8GB/16GB/32GB(optional)
WiFi :
802.11 b/g/n_2.4G (optional)
BT :
Support 4.0
Network :
10M/100M Ethernet;
4G LTE :
Support 4G(optional, default none)
OTA upgrade :
YES
Gravity sensor :
YES
POE function :
YES (optional, default none)
Description



China hot sale 23.1 inch stretch LCD bar display monitor high brightness resolution lcd stretch digital signage display

Stretched LCD Bar Display--AD-23.1ʺ-RK3128


Characteristic:

1, High performance. RK3128 chip with quad-core Cortex-A7, up to 1.2GHz frequency.

2, High stability. RK3128 Andrews one board, in hardware, software, increase their own unique technology to ensure product stability, you can make the final product to 7 * 24 hours unattended.

3, High level of integration RK3128 Andrews integrated board integrated Ethernet, wifi, amplifier, SD card, and so on, greatly simplifying the machine design. Slim-style motherboard design allows the machine design more beautiful.

4, High scalability 3 USB ports, can expand more external devices.

Product Features:

1. Slim and light design.

2. Firm and durable case, made of metal plate.

3. VESA standard wall mount, able to hold kiosk tightly.

4. Able to split screen, able to be double sided, able to make vertical screen.

5. LED backlight, high brightness, clear image.

6. Suitable for super market, shopping mall, subway station, bus station, etc.

7. 19,1’’, 21.9’’, 23.1’’, 28’’, 28.8’’, 35’’, 36.6’’, 38’’ etc. size for option

& screen size can be customized

8. CPU (RK3128/RK3288/ A9)

9. Android OS for option

10. LCD bar screen with WIFI, BT, LAN, 4G LTE optional




PRODUCTS SPECIFICATIONS

System CPU RK3128,quad-core,Cortex A7,1.2G GPU Mali-400MP2
RAM 1GB/2GB (optional)
Storage 8GB/16GB/32GB(optional)
Operation system Android 6.0
Display LCD panel 23.1"
Resolution IPS 1920*158
Contrast ratio 3000:1
Brightness 500cd/m2
Network WiFi 802.11b/g/n(802.11a/b/g/n/ac optional)
Buletooth Buletooth 4.0
Mobile Network Built in 3G/4G LTE(optional, default none) 　 　 　
Ethernet 10M/100M Ethernet
Interface USB interface support USB host*2
Micro USB USB_OTG*1
DC DC power supply 12V input
TF card Maximum support 32GB
RJ45 Ethernet port
Speaker 2W * 8Ω * 2
Media player Video format MPEG-1,MPEG-2,MPEG-4,H.263,H.264,H.265,VC-1,VP8,MVC etc.,max support 1080p
Audio format MP3,WMA,WAV, APE, FLAC, AAC, OGG,M4A,3GPP format
Image Format Support JPG,BMP, PNG,etc,support image rotation/slide show/zoom

System management		 APK installation APK installation
Root permission Original Android system,open root permissions, system customization
Remote control Real-time remote monitoring, system crash self-recovery, 7*24 hours unattended.
OTA upgrade Support OTA remote upgrades
Others Gravity sensor support G-sensor
POE function 　 support POE (optional, default none)
OSD Language Multilingual OSD includes Chinese and English,etc
Color Black
Accessories Adapter Power Adapter 12V/2A
User manual Standard
Warranty Card Standard




PRODUCT SCENARIOS

High Resolution LCD Widescreen Monitor Stretched High Level Of Integration

High Resolution LCD Widescreen Monitor Stretched High Level Of Integration

High Resolution LCD Widescreen Monitor Stretched High Level Of Integration




PACKAGING DETAILS

1, Packaging: film, foam and wooden case (international standard packaging), suitable for export.

2, Lead time: in 1 week for sample order, about 5 weeks for large order.

Our Services:

1) Original guarantee; 2) Competitive prices;

3) Offer 12 months of warranty; 4) Stable supply at least 3-5years; 5)Any question will be reply in 24 hours





OFFICE AND FACTORY

SUNCHIP: Digital Signage manufacturer in Shenzhen, China.

Our main products include Android ARM Board, Floor Standing Display, Wall Mounted Display, Stretched LCD Display, Open Frame Display and Android Media Player Advertising Box.

LOOKING FORWARD TO YOUR INQUIRY AND KIND COOPERATIONS!
WELCOME TO INQUIRE ME~

High Resolution LCD Widescreen Monitor Stretched High Level Of Integration
