Square TFT LCD Screen 1.54 Inch 240 * 240 IPS Module Household Appliance
Square TFT LCD Screen 1.54 Inch 240 * 240 IPS Module Household Appliance
Square TFT LCD Screen 1.54 Inch 240 * 240 IPS Module Household Appliance
Square TFT LCD Screen 1.54 Inch 240 * 240 IPS Module Household Appliance
Square TFT LCD Screen 1.54 Inch 240 * 240 IPS Module Household Appliance
Square TFT LCD Screen 1.54 Inch 240 * 240 IPS Module Household Appliance
Square TFT LCD Screen 1.54 Inch 240 * 240 IPS Module Household Appliance
Square TFT LCD Screen 1.54 Inch 240 * 240 IPS Module Household Appliance
Specifications
Brand Name :
Elite Tree
Model Number :
ET145NP01
Certification :
ISO9001:2015 / ISO14001
Place of Origin :
China
MOQ :
100pcs
Price :
Negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
100Kpcs~ per month
Delivery Time :
5days for sample and 20-25 days for mass production
Packaging Details :
In anti-statics bag packed in carton or according to the customer's requirement
Display Type :
TFT LCD Screen 1.54 Inch 240 * 240
Viewing Direction :
All
Driver IC :
ST7789V
Interface :
SPI
Application :
Smart Watch, Smart Home
Description

Square TFT 1.54 Inch 240 * 240 Resolution TFT LCD Screen IPS Module​↵

TFT LCD Screen

Product Information

Display Type 1.54'' Square TFT LCD Screen
Resolution 240 * 240
Outline Dimension 31.20mm * 35.10mm * 1.40mm
Active area 27.72mm * 27.72mm
Interface SPI
Viewing Direction All
LED backlight color
 White LED
Power supply(typ) 2.8V
Operating temp
 -20ºc~70ºc
Storage temperature -30ºc~80ºc
Brightness 350cd/m2
If accept customized Yes
RoHS compliance Yes

Our advantages


1) Small quantity accepted
2) Competitive price and short lead-time and best service
3) ROHS/ ISO 14001 and other related certificates are available
4) Reply the mail within 24 hours

​Application

Autoelectronics, 3D&Shutter, Meters & Instrument, Telecommunication,

Domestic electrical appliance(Household appliance), Fuel dispensers,

Office equipment, Medical &health equipment, Business related facility, Education electronics, etc.

Product Drawing

​

Square TFT LCD Screen 1.54 Inch 240 * 240 IPS Module Household Appliance
