EDP Interface 10.1 Inch LCD Screen Industrial LCD Display 1280x800 300cd/m2
EDP Interface 10.1 Inch LCD Screen Industrial LCD Display 1280x800 300cd/m2
EDP Interface 10.1 Inch LCD Screen Industrial LCD Display 1280x800 300cd/m2
EDP Interface 10.1 Inch LCD Screen Industrial LCD Display 1280x800 300cd/m2
EDP Interface 10.1 Inch LCD Screen Industrial LCD Display 1280x800 300cd/m2
EDP Interface 10.1 Inch LCD Screen Industrial LCD Display 1280x800 300cd/m2
Specifications
Brand Name :
HG
Model Number :
HG101WX049
Certification :
ROHS/CE/ISO9001
Place of Origin :
Shenzhen China
MOQ :
1pcs
Price :
Negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
350Kpcs/month
Delivery Time :
7-15working days
Packaging Details :
Standard Export Package
Product Name :
10.1-inch industrial LCD display
LCD Type :
TFT
Dot Arrangement :
1280*800
Viewing Angle :
ALL
Luminance :
300cd/m2(customizable）
Signal Type :
EDP interface 30PIN
Description

10.1-inch LCD screen is an EDP interface, TFT, full perspective, resolution of 1280 * 800 industrial LCD display

Product Description

10.1-inch LCD screen is an EDP interface, TFT, full perspective, resolution of 1280 * 800 industrial LCD display, used for industrial-control equipment and industry-related products

Product parameter details

Model HG101WX049 Application industry Industrial control
Size 10.1 inch Arrangement 1280*800
Display size 216.96mm*135.6mm External dimensions 228.3mm*149.05mm*2.4mm
Viewing Angle ALL Luminance 300cd/m2
Contrast ratio 800 NTSC 50%
Signal types EDP interface 30PIN
Temperature

Operating temperature: -20℃ ~ + 60℃,

storage temperature: -30℃ ~ + 70℃
Remark: Can be matched with industrial HDMI board for signal conversion

EDP Interface 10.1 Inch LCD Screen Industrial LCD Display 1280x800 300cd/m2

Description of products

HG10WX049 is a full-view industrial LCD screen,

The resolution is 1280*800, and the effect is IPS

It is composed of TFT LCD panel, driver IC, FPC and backlight.

Using EDP universal 40PIN interface, can work at -20℃~60℃, storage temperature: -30℃~70℃

This product is widely used in industrial control, medical, handheld, security, vehicle, instrumentation and other related products

All products are available with or without touch and industrial drive boards, no matter what configuration you choose,

Can be customized according to your requirements (can be customized backlight, FPC, touch screen, industrial drive board)

It also meets RoHS and CE certification standards

If you can't find a suitable one, please contact us for a recommendation.

EDP Interface 10.1 Inch LCD Screen Industrial LCD Display 1280x800 300cd/m2

Packaging and transportation

Packaging details:

1. All products are packaged correctly to ensure safety.

2. For small-size products, we use the tray = carton.

3. For larger sizes, we use knife cards + foam + cartons.

4. We can also design packaging according to customer requirements.

Transport

1. Through express delivery (3-7 working days),

2. Marine transportation (15-30 days), suitable for conventional mass production.

3. Air transport (4-5 days), from airport to airport.

EDP Interface 10.1 Inch LCD Screen Industrial LCD Display 1280x800 300cd/m2
