OEM / ODM IP65 Industrial PC Embedded IPS Android Tablet 1280*1080
OEM / ODM IP65 Industrial PC Embedded IPS Android Tablet 1280*1080
OEM / ODM IP65 Industrial PC Embedded IPS Android Tablet 1280*1080
OEM / ODM IP65 Industrial PC Embedded IPS Android Tablet 1280*1080
OEM / ODM IP65 Industrial PC Embedded IPS Android Tablet 1280*1080
OEM / ODM IP65 Industrial PC Embedded IPS Android Tablet 1280*1080
Specifications
Brand Name :
LONGYU
Model Number :
LYA101K20S-W
Certification :
CE RoHS
Place of Origin :
China
MOQ :
1 pcs
Price :
TBA
Payment Terms :
T/T, Western Union，Paypal
Supply Ability :
10000PCS/Month
Delivery Time :
7-10 Work Days
Packaging Details :
1-5pcs/CTN, Safe, Firm, suitable for international shipping
Material :
Plastic face frame, metal back cover
Operating System :
Android11.0/Ubuntu18.04/Linux 4.19
CPU :
Cortex A55
IP Grade :
Industrial grade IP65 dustproof and water proof
Power input :
12-30V Recommended value of 24V
Luminance :
350cd/ m²
Angle of view :
Full perspective
Gigabit Ethernet interface :
1-Route 10 / 100 Mbps Ethernet port
Description

Product Description

1280*1080 PC IPS Industrial Android Tablet ODM and OEM Tablet for industry applications

LYA101K20S-W is a high-performance embedded integrated touch screen with the industrial Rockchip RK3568 (quad-core A55 main frequency 2.0 Ghz) CPU as the core. The product features a high-resolution 10.1-inch LED LCD display (resolution 1280*1080) and a 10-point capacitive touch screen. It supports USB, Ethernet, DI / DO, RS232, RS485, CAN, WIFI, BT interface, etc. It is suitable for industrial automation control, HMI, small and medium-sized medical analyzer and other industry applications. Built-alone 0.8T NPU can be used for lightweight AI applications.

Product Performance

Performance Detail

System

 CPU processor RK3568 / Cortex A55 4 core main frequency at 2.0GHZ
Operating System Android11.0/Ubuntu18.04/Linux 4.19
Running memory 2GB/4GB
EMMC 16GB/32GB/64GB/128GB
GPU Mali-G52 1-Core-2EE

Display

 Size 10.1 Inch
Resolving power 1280*800
Touch form Capactive 10 touch
Luminance 350 cd/ m²
Angle of view Full perspective

Material

 Material quality Plastic face frame, metal back cover
Way to stall Flat, outer, embedded
IP protection grade Industrial grade IP65 dustproof and water proof (operating face)

Power

 Power interface 3 PIN*2.54mm terminal DC24V provides power supply
Power input 12-30V Recommended value of 24V

Environmental Characteristics

 Working temperature -10℃ ~ 60℃
Storage temperature -20℃ ~ 70℃
Operating humidity 5-90 RH%
Serial port

2 RS232,2 RS485 / 2 CAN switch;
Audio interface Built-in 1 way 8 euro 5W dual channel speaker output; One 3.5mm audio output and one 3.5mm microphone input
Gigabit Ethernet interface 1 Route 10 / 100 / 1000 Mbps Ethernet port
HDMI interface 1-Way HDMI output
TF 1-Route TF card interface
SIM card 1 Standard drawer-type interface with reserved eSIM interface
RTC 1 Built-in supercapacitor
WIFI/BT 2.4G WIFI / BT4.2
4G interface The GPS function 4G module should be replaced
GPIO 4-way GPIO
USB2.0 3*USB 2.0
USB3.0 1 Vertical USB 3.0 (switch through dial switch)

Warranty Instruction

Our company will provide you the following services with this card and invoice (or copy) in accordance with the provisions listed in this warranty card:

  • The machine is guaranteed for three years. Free warranty for the first year; Only the cost fee will be charged in the second and third years, and the service fee will be charged after three years
  • The warranty period starts from the date of invoice
  • Please keep this warranty card and invoice (or copy) properly. You can enjoy warranty service only if you show them together during the period
  • During the warranty period, failure occurs due to the following conditions:, We will charge a certain fee at its discretion:

Company introduction

Wuhan Longyu Intelligent Technology Co., Ltd has a strong R & D, production, sales and management team. Relying on independently developed embedded computer software system and hardware platform technology, we have carefully developed a series of products, the main products include: man-machine interface touch screen, industrial tablet computer all-in-one, ARM industrial motherboard, industrial display, etc. We strive to promote the upgrading of China's manufacturing industry, the research and development of products are widely used in intelligent transportation, automation equipment, terminal self-help equipment, industrial control, electric power, military industry, finance, network security, Marine manufacturing, medical instruments, numerical control, instrumentation, scientific research and other industries, with many well-known enterprises at home and abroad to maintain long-term stable cooperation.

OEM / ODM IP65 Industrial PC Embedded IPS Android Tablet 1280*1080OEM / ODM IP65 Industrial PC Embedded IPS Android Tablet 1280*1080OEM / ODM IP65 Industrial PC Embedded IPS Android Tablet 1280*1080
OEM / ODM IP65 Industrial PC Embedded IPS Android Tablet 1280*1080
OEM / ODM IP65 Industrial PC Embedded IPS Android Tablet 1280*1080
