Specifications
Brand Name :
LONGYU
Model Number :
LYA104G20I
Certification :
CE RoHS
Place of Origin :
China
MOQ :
1 pcs
Price :
TBA
Payment Terms :
T/T, Western Union,Paypal
Supply Ability :
10000PCS/Month
Delivery Time :
7-10 Work Days
Packaging Details :
1-5pcs/CTN, Safe, Firm, suitable for international shipping
Resolving power :
1024*768
Touch form :
Capacitive 10 touch
angle of view :
Full perspective
CPU :
RK3568 / Cortex A55 4 core main frequency at 2.0GHZ
Size :
10.4 Inch
GPU :
Mali-G52 1-Core-2EE
Description

Product Description

Touch Screen Pc 10.4 inch Waterproof 1024*768 Embedded Industrial Panel PC 1 lan

LYA104K20I is a high-performance embedded integrated touch screen with the industrial core core Micro RK3568 (quad-core A55 main frequency 2.0 Ghz) CPU as the core. The product features a high-resolution 10.4-inch LED LCD display (with a resolution of 1024 * 768). it supports USB, Ethernet, DI / DO, RS232, RS485, CAN, WIFI, BT interface, etc. It is suitable for industrial automation control, man-machine interface, small and medium-sized medical analyzer and other industry applications. Built-alone 0.8T NPU can be used for lightweight AI applications.

Product Feature

DC24V Embedded Panel PC Capacitive Waterproof Touch Screen PC 1 Lan RoHS

Product Performance:

Performance Detail

System

CPU processor RK3568 / Cortex A55 4 core main frequency at 2.0GHZ
Operating System Android11.0/Ubuntu18.04/Linux 4.19
Running memory 2GB/4GB
EMMC 16GB/32GB/64GB/128GB
GPU Mali-G52 1-Core-2EE

Display

Size 10.4 Inch
Resolving power 1024 * 768
Touch form Capactive 10 touch
Luminance 600 cd/ m²
Angle of view Full perspective

Material

Material quality Aluminum alloy face frame, metal back cover
Way to stall Embedded installation
Dimension W293mm×H222mm×54mm
IP protection grade Industrial grade IP64 (operating face)

Power

Power interface 3 PIN*2.54mm terminal DC24V provides power supply
Power input 12V-30V(Recommended value 24V)

Environmental Characteristics

Working temperature -20℃ ~ 70℃
Storage temperature -20℃ ~ 70℃
Operating humidity 5-90 RH%
Serial port

3 RS232,2 RS232 / RS485 / CAN switch;

6-way TTL serial port (reuse with serial port)

Audio interface Ear integrated interface
Gigabit Ethernet interface 1 Route 10 / 100 / 1000 Mbps Ethernet port
HDMI interface 1-Way HDMI output, up to 3840 * 2160 resolution
TF 1-Route TF card interface
SIM card 1 Standard drawer-type interface with reserved eSIM interface
RTC 1 Built-in supercapacitor
WIFI/BT 2.4G WIFI / BT4.2
4G interface The GPS function 4G module should be replaced
GPIO interface Expand miniPCIE 4G module
GPIO 4 input and output: 2 optical coupling input, 2 relay dry contact output;
USB2.0 1 Vertical plug interface USB 2.0,4 horizontal plug interface USB 2.0,1 built-in row pin (USB 2.0)
USB3.0 1 Vertical USB 3.0 (switch through dial switch)

Company introduction

Wuhan Longyu Intelligent Technology Co., LTD. (referred to as "Longyu Intelligent") is a high-tech enterprise focusing on industrial automation touch display products, research and development, production, sales in one. It is headquartered in Optics Valley, China. Wuhan East Lake New Technology Development Zone New energy and environmental protection industry base Gezhouba Sun City Industrial Park. After years of experience accumulation in the automatic control industry, the company fully understands the application of automatic control technology, in-depth study of the development prospects in the field of automatic control, integration of multi-industry resources, integration of advanced industrial computer technology, open up new ideas of automatic control technology, in the development and production of automatic control and embedded computer system has made a huge breakthrough. Become a strong brand company in the field, quickly become a leader in the field of automatic control, products sold at home and abroad.
