Specifications
Brand Name :
Genevision
Model Number :
MD-460
Certification :
CE FCC ROSH CCC
Place of Origin :
China
MOQ :
1pcs
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10000pcs/Month
Delivery Time :
5-15 days
Packaging Details :
Carton box with bubble first, then wooden case package
Screen size :
46'' DID LCD panel
Bezel size :
3.5mm gap
Resolution :
2k 1920*1080
brightness :
500cd 700cd option
Interface :
VGA DVI HDMI BNC DP
Accessories :
install bracket ; cable ; splicer ; software ect
Description

46inch Samsung wall mounted 3*3 LCD video wall full screen display tv wall video price

LCD Video Wall System evolves the superior performance and mission-critical reliability of previous versions LCD Video Wall System to deliver the ultimate LCD video wall solution. Building on the the world’s thinnest profile ultra-narrow bezel LCD’s with industry-leading improvements to video processing, installation, management and off-board electronics, to deliver a next-generation video wall solution.

lcd video wall is available in standard (LX) and high (MX) brightness 46” and 55” models, as well as a 65" 4K high brightness (MX) model, the largest, highest-resolution LCD video wall display in the industry. The series also offers options for protective (Extended Ruggedness and Optics™) technology, passive 3D and interactive multi-touch.also features Software which significantly reduces time spent configuring, operating and monitoring the video wall.
RGB Vertical Stripe

46inch DID LCD panel specification

Diagonal Size 46 inch DID lcd panel
LCD panel Brand SAMSUNG
Pixel Format 1920(RGB)×1080 [FHD] 47PPI
Active Area 1018.08(H)×572.67(V) mm
Bezel Area 1018.28(H)×572.87(V) mm
Configuratio RGB Vertical Stripe
Outline Dim. 1021.98(H)×576.57(V) ×72.1(D) mm
Treatment Antiglare (Haze 44%), Hard coating (3H)
Luminance 500 cd/m² (Typ.)
Contrast Ratio 3000:1 (Typ.) (TM)
Viewing Angle 89/89/89/89 (Typ.)(CR≥10)
Support Color 16.7M 100% sRGB
Spliced Seam 3.5mm bezel size
Frame Rate 60Hz
Interface Type LVDS (2 ch, 8-bit) , 51 pins Connector
Operating Mode 3000:1 (Typ.) (TM)
Operating Mode SVA, Normally Black, Transmissive
Light Source WLED , 50K hours , With LED Driver
Environment Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 65 °C

700cd 46

700cd 46

700cd 46

700cd 46

700cd 46

700cd 46

700cd 46

700cd 46
