3x3 Lcd Video Wall Player 43'' Samsung 1920*1080 HDMI 450cd/㎡ Interactive

43 inch 8mm splicing LCD splicing screen / TV splicing wall monitoring display large screen monitor monitoring splicing screen video conference display product details

[I. Product Features]

1. High-definition resolution (1920 * 1080P), fine picture quality and saturated colors;

2. Intelligent split screen, which adopts extension technology to intelligently split the screen display, any combination, as you like;

3. 3D noise reduction filtering technology, based on the original frame noise reduction, added frame-to-frame noise reduction function;

4, 178 ° wide angle of view, to ensure that the image viewed in the 178 ° angle of view is not deformed, and the color is not distorted;

5. Simulated delivery, the picture can be transmitted to the upper area of ​​the splicing screen through the signal source on mobile devices such as mobile phones and computers for display on the wall of the screen;

6, the body is made of metal, anti-magnetic field, anti-interference, anti-radiation, static electricity;

7. Silent cooling fan design, long machine life.

[Two, product parameters]

1. Product model: JC-XVK-APJP4308LL;

2. Screen size: 43-inch LED;

3. Resolution: 1920X1080P;

4. Screen aspect ratio: 16: 9;

5. Brightness: 500cd / m2;

6. Contrast: 4000: 1;

7. Viewing angle: 178 °;

8. Response time: 5ms;

9. Color: 1.07G (10bit);

10. Refresh rate: 60Hz;

11. Video input (AV): BNC × 2;

12. Video loop-out (AV): BNC × 2;

13. VGA signal input: VGA × 1;

14. DVI digital signal input: DVI × 1;

15. HDMI signal input: HDMI × 1;

16. DP signal input: None;

17. RS-232 control input: RJ45 × 1;

18. USB: USB × 1;

19. RS-232 control loop-out: RJ45 × 2;

20. Debug + IR (for program upgrade and external remote control receiver): RJ45 × 1

21. Open window roaming: 1 sub-picture roaming;

22. Working temperature: 0 ℃ ～ 50 ℃;

23. Storage temperature: -20 ℃ ~ 60 ℃;

24. Working humidity: 5% ~ 90%;

25. Storage humidity: 5% ~ 90%;

26. Reliability: 60,000 hours;

27. Power supply: 100V ~ 240V AC;

28. Working power consumption: 80W;

29. Standby power consumption: ≤3W;

30. Unit size (mm): 936.3 * 538.1 * 89.2;

31. Display area: 930 * 523mm;

32. Patch size (mm): 8mm on both sides;

33. Net weight: about 12kg;

34. Environmental standards: All components and packaging materials meet international environmental standards;

35. Installation method: cabinet type, recessed wall type, bracket type;

36. Appearance color: black;

37. Shell material: sheet metal;

38. Operation mode: RS232 serial port control;

39. Operation mode: 16 kinds.

[III. Application areas]

Suitable for security monitoring, bars / KTV, banks, corporate production scheduling, hospitals, commercial buildings, real estate marketing centers, etc.
