5x5 LCD Video Wall Advertisement Display 3.8mm 500cd Landscape Narrow Bezel
5x5 LCD Video Wall Advertisement Display 3.8mm 500cd Landscape Narrow Bezel
5x5 LCD Video Wall Advertisement Display 3.8mm 500cd Landscape Narrow Bezel
5x5 LCD Video Wall Advertisement Display 3.8mm 500cd Landscape Narrow Bezel
5x5 LCD Video Wall Advertisement Display 3.8mm 500cd Landscape Narrow Bezel
5x5 LCD Video Wall Advertisement Display 3.8mm 500cd Landscape Narrow Bezel
5x5 LCD Video Wall Advertisement Display 3.8mm 500cd Landscape Narrow Bezel
5x5 LCD Video Wall Advertisement Display 3.8mm 500cd Landscape Narrow Bezel
Specifications
Brand Name :
GENEVISION
Model Number :
MD-550DUNTKB1
Certification :
CE FCCC ROSH CCC
Place of Origin :
Shenzhen China
MOQ :
1pcs
Price :
$500-$600
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10000pcs/Month
Delivery Time :
5-8 working days
Packaging Details :
Cartoon box first, Then wooden case safe package
Material :
Metal+Panel
Dimension :
1075.6*605.8*110.9mm
Bezel size :
3.8mm 55'' LCD panel
Brightness :
500cd
Resolution :
2k lcd video wall
Espect Ratio :
16:9
Description

5x5 LCD Video Wall Advertisement Display 3.8mm 500cd Landscape Narrow Bezel

LG 55 inch 3.8mm patchwork,

LG Display LCD 550DUNTKB1 structural characteristics

Panel size: 55 inches

Backlight type: WLED

Point resolution: 1920 (RGB) x1080 (FHD) LG55 inch LCD splicing large screen model 550DUNTKB1 stitching 3.8mm

Aspect ratio: 16: 9 (width: height)

Pixel arrangement: RGB vertical bars

Pitch point spacing: 0.210x0.630mm (horizontal * vertical)

Pixel pitch: 0.630x0.630mm (horizontal * vertical)

Panel weight: 18.1 / 19.0kgs (Typ Max.)

Surface treatment: fog (Haze10%), Hard coating (3H)

Display area: 1209.6x680.4mm (horizontal * vertical)

Visible area: 1209.8x680.6mm (horizontal * vertical)

Appearance size: 1213.4x684.2mm (horizontal * vertical)

Appearance size: 34.6 / 60.4 (Typ Max.) Mm (thickness)

Landscape Portrait: Landscape Mode / Portrait Mode

Touch screen: None

LG Display LCD 550DUNTKB1 optical characteristics

Display mode: IPS, normally black display, transmissive

Panel brightness: 500cd㎡ (Typ.)

Contrast: 1400: 1 (Typ.) (Transmission)

Display color: 1.07B (10-bit)

Color saturation: 72% LG 55-inch LCD splicing large screen model 550DUNTKB1 stitching 3.8mm

Response time: 12 (Typ.) (G toG) (ms)

Viewing angle: 89/89/89/89 / (Min.) (CR≥10) (left / right / up / down)

Best viewing angle: symmetrical up, down, left and right

White chromaticity: X: 0.279; Y: 0.292

White field change: 1.11 / 1.25 (Typ Max.) (9points)

Scanning frequency: 60Hz

Reverse scan: No

Total power consumption: 160.3W (Typ.)

Packing box size: 1440x1140x950mm (length x width x height)

5x5 LCD Video Wall Advertisement Display 3.8mm 500cd Landscape Narrow Bezel

5x5 LCD Video Wall Advertisement Display 3.8mm 500cd Landscape Narrow Bezel

5x5 LCD Video Wall Advertisement Display 3.8mm 500cd Landscape Narrow Bezel

5x5 LCD Video Wall Advertisement Display 3.8mm 500cd Landscape Narrow Bezel

Tag: 55inch lcd video wall ; 5x5 lcd video wall ; narrow bezel lcd video wall
