15.0 inch NLT Industrial Display NL10276AC30-48D 1024*768 XGA LCD Screen Panel
15.0 inch NLT Industrial Display NL10276AC30-48D 1024*768 XGA LCD Screen Panel
15.0 inch NLT Industrial Display NL10276AC30-48D 1024*768 XGA LCD Screen Panel
15.0 inch NLT Industrial Display NL10276AC30-48D 1024*768 XGA LCD Screen Panel
15.0 inch NLT Industrial Display NL10276AC30-48D 1024*768 XGA LCD Screen Panel
15.0 inch NLT Industrial Display NL10276AC30-48D 1024*768 XGA LCD Screen Panel
Specifications
Brand Name :
NEC
Model Number :
NL10276AC30-48D
Place of Origin :
China
MOQ :
1 pcs
Price :
Negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
100000 Unit/Units per Month
Delivery Time :
7 Days
Packaging Details :
Original packaging/conventional packaging box
Model P/N :
NL10276AC30-48D
Diagonal Size :
15.0"
Resolution :
1024(RGB)×768, XGA 85PPI
Active Area :
304.128(W)×228.096(H) mm
Bezel Opening :
307.4(W)×231.3(H) mm
Outline(mm) :
326.5 × 253.5 (H×V×D)
Luminance :
350 cd/m² (Typ.)
Response :
14/11 (Typ.)(Tr/Td) ms
Mass :
870/920g (Typ./Max.)
Used for :
Industrial
Description

15.0 inch NLT Industrial Display NL10276AC30-48D 1024*768 XGA LCD Screen Panel

NL10276AC30-48D Product details :

NEC LCD Screen NL10276AC30-48D
Manufacturer NEC
Model Name NL10276AC30-48D
Screen Size 15.0 inch
Types of a-Si TFT-LCD, LCD module
Resolution 1024(RGB)*768 XGA 85PPI
Pixel arrangement RGB vertical bar
Display area 304.128(H)*228.096(V) mm
physical dimension 326.5(H)*253.5(V) mm
Open area 307.4(H)*231.3(V) mm
Surface treatment Matte, Hard coating (3H)
Display brightness 350 cd/m² (Typ.)
Contrast 900:1 (Typ.) (transmission)
Recommended perspective Full view
Response time 14/11 (Typ.)(Tr/Td) ms
Viewing angle 88/88/88/88 (Typ.)(CR≥10)
Display mode SFT, normally black display, transmissive
Support color 262K/16.2M, 72% NTSC
type of light source WLED, 50K hours, with LED driver
weight 870/920g (Typ./Max.)
Frame rate 60Hz
Touch technology No touch
Interface Type 20 pins LVDS (1 ch, 6/8-bit), connector
Voltage supply 3.3V (Typ.)
Application Environment Working temperature: -20 ~ 70 °C; Storage temperature: -20 ~ 80 °C
15.0 inch NLT Industrial Display NL10276AC30-48D 1024*768 XGA LCD Screen Panel

NL10276AC30-48D Payment:

We accept alipay here.

All major credit cards are accepted through secure payment processor ESCROW.

We also accept T/T, Western Union, Moneygram.

NL10276AC30-48D Shippment & Packing

15.0 inch NLT Industrial Display NL10276AC30-48D 1024*768 XGA LCD Screen Panel

NL10276AC30-48D Shipping:

We Ship to Worldwide via DHL, UPS, FEDEX, TNT, CPAM, we also have our own cargo to ship the goods worldwise with cheaper price.

Items are shipped via DHL, UPS, FEDEX, TNT, reach most of the countryes whith in 5-15 business days.

Items are shipped from China using Airmail, reach most of the countries within 10 to 40 business days.

NL10276AC30-48D Returns :

*All returns must be notified before the return. We look forward to cooperating with rational and friendly customers. If you have any problems with the items you received, please contact us immediately.

*Because the buyer ordered the wrong parts, the buyer needs to pay the replacement shipping cost.

*The returned goods must have all original packaging and be in good condition.

*All items will be tested before shipment. If you encounter any problems, please contact me first and I will try my best to solve it for you. Don't accept bad reviews before contacting me.

NL10276AC30-48D FAQ:

Q: If I place order now,when will you ship the goods of NL10276AC30-48D ?

A: The order will be shipped within 2-3 working days after received your payment.

Q: Can you give me a discount if I need a large quantity of NL10276AC30-48D ?

A: Of course!If you make a large order, we will give you a discount.

Q: How long will I receive my goods NL10276AC30-48D ?

A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.

Q: Can I pay my order of NL10276AC30-48D via credit card ?

A: Yes!you can use your credit card through your Paypal account.
