Specifications
Brand Name :
NEC
Model Number :
NL2432HC22-36B
Place of Origin :
China
MOQ :
1 pcs
Price :
Negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
100000 Unit/Units per Month
Delivery Time :
7 Days
Packaging Details :
Original packaging/conventional packaging box
Model Name :
NL2432HC22-36B
Diagonal Size :
3.5"
Resolution :
240(RGB)×320, QVGA 113PPI
Active Area :
53.64(W)×71.52(H) mm
Luminance :
350 cd/m² (Typ.)
Pixel layout :
RGB Vertical Stripe
Used for :
Handheld & PDA
Description

3.5 inch NL2432HC22-36B LCD Touch display

NL2432HC22-36B LCD Panel Product details :

NEC LCD Screen NL2432HC22-36B
Manufacturer NEC
Model Name NL2432HC22-36B
Screen Size 3.5inch
Panel Type a-Si TFT-LCD, LCM
Resolution 240(RGB)×320, QVGA 113PPI
Pixel layout RGB Vertical Stripe
Active Area 53.64(W)×71.52(H) mm
Bezel Opening 56.64(W)×75.52(H) mm
Outline (mm) 64(W)×85(H) ×4.85(D) mm
Treatment Antiglare, Hard coating (3H)
Luminance 350 cd/m² (Typ.)
Contrast Ratio 300:1 (Typ.) (TM)
Viewing angle 30/60/55/55 (Typ.)(CR≥10)
Response 8/15 (Typ.)(Tr/Td)
View Direction 9 o'clock
Work Mode TN, Normally White, Transmissive
Color Depth 262K/16.7M 36% NTSC
Backlight WLED , Without Driver
Mass 37.0g (Typ.)
Used for Handheld & PDA
Refresh Rate 60Hz
Touchscreen 4-wire Resistive Touch
Signal Type CMOS (1 ch, 6-bit) , 50 pins FPC
Voltage Supply 3.0/5.0/15.0/-15.0V (Typ.)(VCC/VDD/VGON/VGOFF)
Environment Operating Temp.: -10 ~ 55 °C ; Storage Temp.: -20 ~ 70 °C
3.5 inch NL2432HC22-36B LCD Touch display

NL2432HC22-36B LCD Panel Shipping and Package :

3.5 inch NL2432HC22-36B LCD Touch display

Shipping Terms for NL2432HC22-36BScreen:

Efficient Shipping Agency: Partnering with the most reputable and powerful shipping agencies, we guarantee professional and swift shipping services. With our trusted partners, you can expect your order to be handled with utmost care and delivered to you in optimal condition.

Fast Delivery Worldwide: We understand the importance of prompt delivery. Typically, your NL2432HC22-36B LCD Screen will be dispatched within 24 hours of placing your order. With our efficient shipping methods, delivery times are estimated to be within 3-7 business days worldwide. We prioritize expediency without compromising on the safety of your shipment.

Import Duties and Taxes: Please note that import duties, taxes, and other charges may apply depending on your location and local customs regulations. These additional fees are not included in the purchase price or shipping cost. Customers are responsible for any applicable import duties, taxes, or charges incurred upon receiving their order. We advise you to familiarize yourself with your country's import policies to avoid any unexpected expenses.


After-Service Note for NL2432HC22-36B LCD Screen:

Exclusions from Warranty Coverage: Our warranty does not cover damages resulting from man-made factors or natural disasters. Examples include, but are not limited to, improper installation, physical damage such as nicks or scratches, malfunction due to improper handling, or damage caused by external factors like power surges or environmental hazards.

Warranty Fragile Tags: To facilitate warranty claims, each product sold by our store is equipped with warranty fragile tags. These tags serve as evidence of warranty coverage. If these tags are tampered with or removed during the warranty period, it will be considered a breach of warranty terms.

Waiver of Warranty: Any deliberate disconnection or loss of the product's warranty fragile tags will be interpreted as the customer's decision to waive warranty coverage. In such cases, we cannot accept responsibility for any subsequent issues or damages.

Please be mindful of these terms and conditions to ensure a smooth after-sales experience. Should you have any questions or concerns regarding warranty coverage or after-service support, do not hesitate to reach out to our dedicated customer service team.


Refund & Return Policy for NL2432HC22-36B LCD Screen:

Damaged During Transportation: We understand the concerns associated with shipping delicate items. Rest assured, if your LCD screen arrives damaged due to transportation mishaps, we offer a hassle-free refund. Simply notify us of the damage, and we will initiate the refund process promptly.

Secure Packaging Guarantee: Your peace of mind is paramount to us. With meticulous attention to detail, we ensure that every LCD screen is packed securely to withstand the rigors of transit. Trust in our packaging expertise, and bid farewell to worries regarding the safety of your shipment.

Item Not as Described: Your satisfaction with our products is our top priority. In the unlikely event that the received item does not align with the provided description, you have the option to return it. We value transparency and strive to uphold the accuracy of product descriptions, but if discrepancies arise, we stand ready to address them swiftly.

NL2432HC22-36B LCD Panel FAQ :

Q: Can you give me a discount if I need a large quantity of NL2432HC22-36B?

A: Of course!If you make a large order, we will give you a discount.

Q: Can You declare my order of NL2432HC22-36B to a lower price in commercial invoice for customs ?

A: Yes , we can . pls inform us before shipping .

Q: Can I pay my order of NL2432HC22-36B via credit card ?

A: Yes!you can use your credit card through your Paypal account.

Q: How long is the warranty ?

A: We offer 90days warranty .
