B173HTN01.1 Laptop Lcd Screen Display Monitor Panel Replacement 1920*1080 EDP 30 Pins
B173HTN01.1 Laptop Lcd Screen Display Monitor Panel Replacement 1920*1080 EDP 30 Pins
B173HTN01.1 Laptop Lcd Screen Display Monitor Panel Replacement 1920*1080 EDP 30 Pins
B173HTN01.1 Laptop Lcd Screen Display Monitor Panel Replacement 1920*1080 EDP 30 Pins
Specifications
Brand Name :
AUO
Model Number :
B173HTN01.1
Place of Origin :
China
MOQ :
1 pcs
Price :
Negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
100000 Unit/Units per Month
Delivery Time :
7 Days
Packaging Details :
Original packaging/conventional packaging box
Model Name :
B173HTN01.1 (AUO119D)
Screen Size :
17.3 inch
Resolution :
1920(RGB)×1080 (FHD) 127PPI
Display Area :
381.888(H)×214.812(V) mm
Outline(mm) :
398.1(H)×233.3(V) ×6(D) mm
Outline Shape :
Wedge (PCBA Bent, T≥5.2mm)
Luminance :
300 cd/m² (Typ.)
Contrast Ratio :
600:1 (Typ.) (TM)
Description

17.3 inch B173HTN01.1 Laptop Lcd Screen display monitor panel replacement 1920*1080 EDP 30 Pins

Product details :

AUO LCD SCREEN B173HTN01.1 (AUO119D)
Panel Brand AUO
Panel Model B173HTN01.1 (AUO119D)
Panel Size 17.3"
Panel Type a-Si TFT-LCD , LCM
Resolution 1920(RGB)×1080, FHD, 127PPI
Pixel Format RGB Vertical Stripe
Display Area 381.888(W)×214.812(H) mm
Outline Size 398.1(W)×233.3(H)×6(D) mm
Surface Matte surface, Hard coating (3H), reflectivity 4.3% (Typ.)
Brightness 300 cd/m² (Typ.)
Contrast Ratio 600:1 (Typ.) (TM)
Viewing Angle 70/70/60/60 (Typ.) (CR≥10)
Display Mode TN, Normally White, Transmissive
Response Time 8 (Typ.)(Tr+Td) ms
Display Colors 262K , 72% NTSC
Lamp Type WLED , 15K hours, with LED driver
Frequency 60Hz
Touch Screen Without
Form Style Wedge (PCBA Bent, T≥5.2mm)
Designed For Laptop
Signal Interface eDP (2 Lanes) , eDP1.2 , 30 pins , terminal
Input Voltage 3.3V (Typ.)
Environment Operating temperature: 0 ~ 50 °C ; Storage temperature: -20 ~ 60 °C
17.3 inch B173HTN01.1 Laptop Lcd Screen display monitor panel replacement 1920*1080 EDP 30 Pins

-guarantee

1. All items will be strictly tested before shipment.

2. The warranty period is 90 days.

- Refunds and returns

1. If the item is defective, please notify us within 3 days after receiving the item.

2. If possible, items should be returned in their original packaging.

Note: Due to regional weather and other factors, the delivery time of China Post Ai Mail will take 10-50 days. Please be patient if you choose China Post Airmail

Why Choose Us :

According to customers' various requests,


we can match all accessories which inclusive of driver board,


touch-screen, LED backlight & LVDS cables. TFT LCD,


LCD panel, LCD display,LCD screen, LCD monitor,


LCD module from 2.2 inch to 88 inch.


Quality promised, 100% original,fast delivery,


also enjoy one year guarantee !

Shipping and Package :

B173HTN01.1 Laptop Lcd Screen Display Monitor Panel Replacement 1920*1080 EDP 30 Pins

1)All of our product will be testing before shipping . So you can be assured the quality of our products

2) All Panels are packed with new and firm carton, capable of long distance transportation.

3) Shipping accepted: FEDEX, DHL, UPS, TNT, EMS, AIR FREIGHT, SEA FREIGHT

4) Delivery time: as we have huge stock, orders only takes 1-3 working days after reveived the payment, and will use third parties delivery services or delivered as clients request.

FAQ:

Q: Do you accept sample orders of B173HTN01.1 (AUO119D) ?

A: Of course!sample order is welcome !

Q: How can I trace my order of B173HTN01.1 (AUO119D) ?

A: we will give you tracking number then you can trace your order from website.

Q: How long is the warranty ?

A: We offer 90 days warranty .

Q: How to make payment of B173HTN01.1 (AUO119D) ?

A: We accept T/T , Paypal , western union .
