AUO 15.6 LCD Panel G156HTN02.0 Vertical Stripe 141PPI Industrial LCD Screen
AUO 15.6 LCD Panel G156HTN02.0 Vertical Stripe 141PPI Industrial LCD Screen
AUO 15.6 LCD Panel G156HTN02.0 Vertical Stripe 141PPI Industrial LCD Screen
AUO 15.6 LCD Panel G156HTN02.0 Vertical Stripe 141PPI Industrial LCD Screen
AUO 15.6 LCD Panel G156HTN02.0 Vertical Stripe 141PPI Industrial LCD Screen
AUO 15.6 LCD Panel G156HTN02.0 Vertical Stripe 141PPI Industrial LCD Screen
Specifications
Brand Name :
AUO
Model Number :
G156HTN02.0
Place of Origin :
CHINA
MOQ :
1 pcs
Price :
Negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
100000 Unit/Units per Month
Delivery Time :
7 Days
Packaging Details :
Original packaging/conventional packaging box
Model :
G156HTN02.0
Diagonal Size :
15.6 inch
Pixel Format :
1920(RGB)×1080 [FHD] 141PPI
Active Area :
344.16(H)×193.59(V) mm
Outline Dim. :
363.8(H)×215.9(V)×9.8(D) mm
Bezel Area :
347.06(H)×196.49(V) mm
Weight :
0.94/1.10Kgs (Typ./Max.)
Designed For :
Industrial
Description

AUO 15.6" LCD Panel G156HTN02.0 Vertical Stripe 141PPI Industrial LCD Screen

G156HTN02.0 Product details :

AUO LCD SCREENG G156HTN02.0
Manufacturer AUO
Model Name G156HTN02.0
Screen Size 15.6"
Screen Type LCM , a-Si TFT-LCD
Pixel Number 1920(RGB)×1080 (FHD) 141PPI
Arrangement RGB Vertical Stripe
Active Area(mm) 344.16 × 193.59 (H×V)
Outline(mm) 363.8 × 215.9 × 9.8 (H×V×D)
Bezel Area(mm) 347.06 × 196.49 (H×V)
Treatment Antiglare, Hard coating (3H)
Luminance 400 cd/m² (Typ.)
Contrast Ratio 700 : 1 (Typ.) (TM)
Viewing Angle 80/80/70/70 (Typ.)(CR≥10)
Response 8 (Typ.)(Tr+Td) ms
Work Mode TN, Normally White, Transmissive
Color Depth 16.7M 72% NTSC
Backlight WLED , 50K hours , With LED Driver
Mass 0.94/1.10Kgs (Typ./Max.)
Used for Industrial
Refresh Rate 60Hz
Touchscreen Without
Signal Type LVDS (2 ch, 8-bit) , 30 pins Connector
Voltage Supply 3.3V (Typ.)
Max. Ratings Storage Temp.: -20 ~ 70 °C Operating Temp.: -10 ~ 70 °C
AUO 15.6" LCD Panel G156HTN02.0 Vertical Stripe 141PPI Industrial LCD Screen

G156HTN02.0 About us:


We mainly sell Industrial LCD panel and touch screen, provides the product information,technical consultation for all kinds of LCD screen and touch screen, We have many stock parts for 1.5-88 inches is between the various industrial screen,Theya are applicable to vehicle,medical equipment, injection molding machine , industrial equipment etc. Welcome to order.


We are saleing TFT LCD module for the PDA,GPS,game device and mobile phone and it is one of the largest scale and best after-service company in the area of PDA spare parts.

G156HTN02.0 Shipping and Package :

AUO 15.6

G156HTN02.0 PACKAGE:


Standard export carton packing.

G156HTN02.0 DELIVERY TIME:


3-20 days after confirming order,detail delivery date should be decided according to production season and order quantity.

G156HTN02.0 Note:


If the quantity of order is not very big,we could send them to you by express delivery,such as TNT,DHL,UPS OR EMS etc.


If order is big ,we will advise you use Air Shipping or Sea Shipping through your nominated forwarder agent.Our long-term cooperated agent also available.

G156HTN02.0 FAQ :

Q: If I place order now,when will you ship the goods of G156HTN02.0 ?

A: The order will be shipped within 2-3 working days after received your payment.

Q: Can I pay my order of G156HTN02.0 via credit card ?

A: Yes!you can use your credit card through your Paypal account.

Q: How long is the warranty ?

A: We offer 90days warranty .

Q: Can You declare my order of G156HTN02.0 to a lower price in commercial invoice for customs ?

A: Yes , we can . pls inform us before shipping .

*Pls feel free to contact us for any questions or special requirements . Thank you so much for your coopreation !
