Specifications
Brand Name :
PANDA
Model Number :
LM156LF2F01
Place of Origin :
CHINA
MOQ :
1 pcs
Price :
Negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
100000 Unit/Units per Month
Delivery Time :
7 Days
Packaging Details :
Original packaging/conventional packaging box
Model Name :
LM156LF2F01 (NCP004D)
Screen Size :
15.6 inch
Screen Type :
LCM , Oxide TFT-LCD
Active Area(mm) :
344.16 × 193.59 (H×V)
Outline(mm) :
350.66 × 216.245 × 3.2 (H×V×D)
Contrast Ratio :
1200 : 1 (Typ.) (TM)
Outline Shape :
Slim (PCBA Flat, T≤3.2mm)
Used for :
Laptop / Gaming
Description

15.6 inch 144Hz laptop LED LCD Screen for ASUS FX505 FX506 FX507 LM156LF2F01 40 pins

LM156LF2F01 (NCP004D) Product details :

PANDA LCD Screen LM156LF2F01 (NCP004D)
Brand PANDA
Model LM156LF2F01 (NCP004D)
Diagonal Size 15.6 inch
Type Oxide TFT-LCD , LCM
Pixel Format 1920(RGB)×1080 [FHD] 141PPI
Configuration RGB Vertical Stripe
Active Area 344.16(H)×193.59(V) mm
Outline Dim. 350.66(H)×216.245(V)×3.2(D) mm
Treatment Antiglare, Hard coating (3H)
Luminance 250 cd/m² (Typ.)
Contrast Ratio 1200:1 (Typ.) (TM)
View Direction Symmetry
Response Time 25 (Typ.)(Tr+Td)
Viewing Angle 85/85/85/85 (Typ.)(CR≥10)
Operating Mode FFS, Normally Black, Transmissive
Support Color 16.7M 45% NTSC
Light Source WLED , 15K hours , With LED Driver
Form Style Slim (PCBA Flat, T≤3.2mm)
Designed For Laptop / Gaming
Frame Rate 144Hz
Touch Panel Without
Interface Type eDP (4 Lanes) , eDP1.3 , HBR1 (2.7G/lane) 40 pins Connector
Power Supply 3.3V (Typ.)
Environment Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C
15.6 inch 144Hz laptop LED LCD Screen for ASUS FX505 FX506 FX507 LM156LF2F01 40 pins

LM156LF2F01 (NCP004D) Attention:


To avoid wrong order placed or wrong item you bought, here is something you need to read before ordering,


1. Please check your laptop model in compatible list or tell if wide screen or standard screen.


2. Please check the LCD screen size and resolution.


3. Please check the Data connector (14pin, 20pin, 30pin(S M L) ,40pin(S,M,L), 50pin 60pin ) and position


4. Please check the physical resolution pixels of LCD screen.

LM156LF2F01 (NCP004D) Payment:


1: We accept Alipay, PayPal,Western Union, TT here


2: All major credit cards are accepted through secure payment proces-sor ESCROW


3: Please make sure you read the entire description and agree to the transaction before buying.

LM156LF2F01 (NCP004D) Shipping and Package :
15.6 Inch 144Hz Laptop LED LCD Screen For ASUS FX505 FX506 FX507 LM156LF2F01 40 Pins

LM156LF2F01 (NCP004D) Shipment:


· We're not responsible for any accidents delays or other issues that are the resposibility of the shipping service.But we will help you to track the package until you get.

· Please make sure to double check your address before completing your payment.

· An email will be sent as package is process for shipment .We will provide tracking number for you to check the package online.

· Customers are responsible for customs taxes and duties where applicable.

· Any import charges or fees are the buyer's responsibility. If the package can't be delivered because of the buyers reason(including refusing to sign), buyer should afford all the extra cost!

LM156LF2F01 (NCP004D) Returns and warranty:

1. All goods must be checked before delivery, so if you are not satisfied with the purchase, you can replace the item within a week, and you will contact us within 24 hours after receiving the purchase.

2. All items have a 3-month warranty. If there is no problem, we will replace it for you free of charge. We have the best after-sales service. If there is any problem, we will do our best to solve the problem for our customers.

3. All returned items must be kept in their original condition, including boxes and accessories. Man-made defects are not guaranteed, such as breakage, scratches, etc.

LM156LF2F01 (NCP004D) FAQ:

Q: How to make payment of LM156LF2F01 (NCP004D)?

A: We accept T/T , Paypal , western union .

Q: Do you accept sample orders of LM156LF2F01 (NCP004D) ?

A: Of course!sample order is welcome !

Q: Can I pay my order of LM156LF2F01 (NCP004D) via credit card ?

A: Yes!you can use your credit card through your Paypal account.

Q: Can You declare my order of LM156LF2F01 (NCP004D) to a lower price in commercial invoice for customs ?

A: Yes , we can . pls inform us before shipping .
