12.1 Inch TFT LCD Module Display BA121S01-200 RGB 800x600 SVGA 82PPI
12.1 Inch TFT LCD Module Display BA121S01-200 RGB 800x600 SVGA 82PPI
12.1 Inch TFT LCD Module Display BA121S01-200 RGB 800x600 SVGA 82PPI
12.1 Inch TFT LCD Module Display BA121S01-200 RGB 800x600 SVGA 82PPI
12.1 Inch TFT LCD Module Display BA121S01-200 RGB 800x600 SVGA 82PPI
12.1 Inch TFT LCD Module Display BA121S01-200 RGB 800x600 SVGA 82PPI
12.1 Inch TFT LCD Module Display BA121S01-200 RGB 800x600 SVGA 82PPI
12.1 Inch TFT LCD Module Display BA121S01-200 RGB 800x600 SVGA 82PPI
Specifications
Brand Name :
BOE
Model Number :
BA121S01-200
Place of Origin :
China
MOQ :
1 pcs
Price :
Negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
100000 Unit/Units per Month
Delivery Time :
7 Days
Packaging Details :
Original packaging/conventional packaging box
Model :
BA121S01-200
Diagonal Size :
12.1 inch
Pixel Format :
800(RGB)×600 [SVGA] 82PPI
Active Area :
246(H)×184.5(V) mm
Outline Dim. :
279(H)×209(V)×9.3(D) mm
Bezel Area :
249.05(H)×188.30(V) mm
Weight :
500g (Max.)
Designed For :
Industrial
Description

BA121S01-200 Original TFT 12.1 inch TFT LCD Module Display BA121S01-200

BA121S01-200 Product details :

BOE LCD SCREEN BA121S01-200
Panel Brand BOE
Panel Model BA121S01-200
Panel Size 12.1"
Panel Type a-Si TFT-LCD, LCM
Resolution 800(RGB)×600, SVGA,82PPI
Pixel Format RGB Vertical Stripe
Display Area 246(W)×184.5(H) mm
Bezel Opening 249.05(W)×188.30(H) mm
Outline Size 279(W)×209(H) ×9.3(D) mm
Surface Clear
Brightness 400 cd/m² (Typ.)
Contrast Ratio 800:1 (Typ.) (TM)
Viewing Angle 80/80/65/75 (Typ.)(CR≥10)
Display Mode TN, Normally White, Transmissive
Best View on 12 o'clock
Response Time 30 (Typ.)(Tr+Td)
Display Colors 262K/16.7M 55% NTSC
Lamp Type WLED , 30K hours , With LED Driver
Frequency 60Hz
Touch Screen Without
Panel Weight 500g (Typ.)
Signal Interface LVDS (1 ch, 6/8-bit) , 20 pins Connector
Input Voltage 3.3V (Typ.)
Environment Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C
BA121S01-200 Original TFT 12.1 inch TFT LCD Module Display BA121S01-200

BA121S01-200 Product condition:

Because of the fluctuant sales situation. the stock parts are always changing and the stock list cannot be promptly updated. So please consult the stock situation when you inquire.

BA121S01-200 Payment Term:


our company accept T/T, Western union,Paypal, Alipay for payment, Please inform us if you have a prefer payment way.

BA121S01-200 Shipping and Package :

12.1 Inch TFT LCD Module Display BA121S01-200 RGB 800x600 SVGA 82PPI

BA121S01-200 Shipping:


We can shipping all over the world by DHL, UPS,FEdex,TNT and EMS. The packaging is very safe and strong. Please nitfy me you have any special needs.


lt will take around 3-5 days to reach your hands.

BA121S01-200 Warranty:

Please confirm receipt of products if the items you received, and if the goods was damaged please contact us immediately. send the photo to us that we can check and give you best solution.


We only guarantee delivery in time but we couldn't control the express delivery time. Our related sales person will be responsible to send the AWB for the delivered goods in the next workday. you can check the AWB in the website which we send to you. For the AWB you also can call to the local branch of the express company in your company.


If you have any other questions please feel free to contact us.

BA121S01-200 FAQ:

Q: Can You declare my order of BA121S01-200 to a lower price in commercial invoice for customs ?

A: Yes , we can . pls inform us before shipping .

Q: How long will I receive my goods BA121S01-200 ?

A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.

Q: Can you give me a discount if I need a large quantity of BA121S01-200 ?

A: Of course!If you make a large order, we will give you a discount.

Q: If I place order now,when will you ship the goods of BA121S01-200 ?

A: The order will be shipped within 2-3 working days after received your payment.
