P320HVN04.3 32.0 inch 1920*1080 FHD LCD Panel Display
P320HVN04.3 32.0 inch 1920*1080 FHD LCD Panel Display
Specifications
Brand Name :
AUO
Model Number :
P320HVN04.3
Place of Origin :
China
MOQ :
1 pcs
Price :
Negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
100000 Unit/Units per Month
Delivery Time :
7 Days
Packaging Details :
Original packaging/conventional packaging box
Model Name :
P320HVN04.3
Diagonal Size :
32.0"
Panel Type :
a-Si TFT-LCD, LCM
Resolution :
1920(RGB)×1080, FHD 69PPI
Pixel Format :
RGB Vertical Stripe
Active Area :
698.4(W)×392.85(H) mm
Work Mode :
AMVA3, Normally Black, Transmissive
Support Color :
16.7M 72%sRGB
View Direction :
Symmetry
Used for :
Digital Signage、Outdoor High Brightness
Description

P320HVN04.3 32.0 inch 1920*1080 FHD LCD Panel Display

P320HVN04.3 LCD Panel Product details :

Brand AUO
Model P/N P320HVN04.3
Diagonal Size 32.0"
Panel Type a-Si TFT-LCD, LCM
Resolution 1920(RGB)×1080, FHD 69PPI
Pixel Format RGB Vertical Stripe
Active Area 698.4(W)×392.85(H) mm
Bezel Opening 701.46(W)×395.85(H) mm
Outline (mm) 721.2×415.65×58.5 (H×V×D)
Treatment Antiglare (Haze 28%), Hard coating (3H)
Luminance 1500 cd/m² (Typ.)
Contrast Ratio 4000 : 1 (Typ.) (TM)
Viewing Angle 89/89/89/89 (Typ.)(CR≥10)
Response 8 (Typ.)(G to G) ms
Good View at Symmetry
Work Mode AMVA3, Normally Black, Transmissive
Color Depth 16.7M 72%sRGB
Backlight WLED, 50K hours, With LED Driver
Mass 5.20Kgs (Typ.)
Used for Digital Signage,Outdoor High Brightness
Refresh Rate 60Hz
Touchscreen Without
Signal Type LVDS (2 ch, 8-bit), Connector51 pins
Voltage Supply 12.0V (Typ.)
Max. Ratings Storage Temp.: -20 ~ 60 °C Operating Temp.: -20 ~ 60 °C
P320HVN04.3 LCD Screen - Extremely Important Information :
1. Product Image and Description Review:
Carefully examine the product image and description provided. This will help you verify that the screen matches your expectations and requirements.
2. Key Specifications Match:
Screen Size: Ensure that the size of the LCD screen matches the specifications required by your device.
Resolution: Confirm that the resolution of the screen is the same as what your device supports. An incorrect resolution can result in poor display quality or incompatibility.
Connector Type: The connector type must be identical to your current screen's connector. Using a screen with a different connector type will prevent it from working properly with your device.
P320HVN04.3 LCD Screen - Also Note :
1. 100% Compatible Screen Guarantee:
You will receive a screen that is 100% compatible with your device.
The exact brand and part number of the screen provided may vary depending on market availability. Rest assured, the replacement screen will meet the necessary specifications for your device.
2. Professional Installation Recommended:
For optimal performance and to avoid any potential damage, we strongly recommend that the screen be installed by a professional repair shop or an experienced individual.
Proper installation is crucial to ensure the screen functions correctly and to maintain the integrity of your device.

P320HVN04.3 LCD Panel Shipping and Package :

P320HVN04.3 32.0 inch 1920*1080 FHD LCD Panel Display

P320HVN04.3 LCD Screen - Shipping Information :
1. Order Processing and Delivery Time:
We will dispatch your goods within 1-3 working days after receiving your order.
Typically, you can expect to receive your order within 27 calendar days from the shipping date.
2. Accurate Shipping Information:
Ensure that your shipping details, including the address, postal code, phone number, and contact person, are accurate before placing your order.
If you need the order to be sent to a different address, please inform us in advance and leave a message in our transaction. This will help us to make the necessary adjustments promptly.
Following these guidelines will help ensure a smooth shipping process and timely delivery of your P320HVN04.3 LCD screen.

P320HVN04.3 LCD Panel FAQ :

Q: If I place order now,when will you ship the goods of P320HVN04.3 ?

A: The order will be shipped within 2-3 working days after received your payment.

Q: Can you give me a discount if I need a large quantity of P320HVN04.3 ?

A: Of course!If you make a large order, we will give you a discount.

Q: How long will I receive my goods P320HVN04.3 ?

A: Generally speaking ,It will take 3-8days to your hand by DHL/FEDEX/UPS/TNT.

Q: How to make payment of P320HVN04.3 ?

A: We accept T/T , Paypal , western union .
