RYG320240D 320x240 Dots COG LCD Module Replace HANTRONIX HDG320240
RYG320240D 320x240 Dots COG LCD Module Replace HANTRONIX HDG320240
RYG320240D 320x240 Dots COG LCD Module Replace HANTRONIX HDG320240
RYG320240D 320x240 Dots COG LCD Module Replace HANTRONIX HDG320240
RYG320240D 320x240 Dots COG LCD Module Replace HANTRONIX HDG320240
RYG320240D 320x240 Dots COG LCD Module Replace HANTRONIX HDG320240
Specifications
Brand Name :
ROYAL DISPLAY
Model Number :
RYG320240D
Certification :
SGS ROHS
Place of Origin :
CHINA
MOQ :
500pcs
Supply Ability :
10k/Month
Delivery Time :
25~28 Working Days
Packaging Details :
220pcs/CTN 11Kg L45*W36*H32CM
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Product Name :
COG Graphic LCD Module For Industrial Application RYG320240A 320x240 Dots 100% replace HANTRONIX HDG320240
Model No. :
RYG320240D
Dot Format :
320X240
LCD Type :
FSTN Postive
Viewing Angle :
6 O' clock
LED Backlight :
White
Operating Temp :
-20º C~70º C
Price :
Negotiable
Description

COG Graphic LCD Module For Industrial Application RYP320240D 320x240 Dots 100% replace HANTRONIX HDG320240

1. 320x240 dots
2. Parallel interface
3. STN-blue, STN-Positive display results as option

4. Ultra high contrast, YG & White LED backlight as option

Item Description
Product Name 320X240 dots Graphic LCD Module
Model No. RYG320240d
Dot Format 320x 240
Outline Dimension(mm) 88.3x69.1
Viewing Area(mm) 79.8 x 57.85
Pixel Size( mm) 0.24 x 0.24
Viewing Angle 6 O' clock
LCD Type FSTN-Positive, STN-Blue
Backlight White or Y/G LED backlight
Controller NT7701&NT7709
Power supply 3V
Interface Parallel
Operating Temp -20º C~70º C
Storage Temp -30º C~80º C

RYG320240D 320x240 Dots COG LCD Module Replace HANTRONIX HDG320240

Typical Applications:

Clusters, Car Radios, Air conditioner, Home Automation, Industrial Instruments, etc
Features:
Transmissive, Transflective and Reflective Model

Wide Operation & Storage temperature range
Duty Ratio: up to 1:240

support gray scale display

RYG320240D 320x240 Dots COG LCD Module Replace HANTRONIX HDG320240
