240×320 Dots TFT LCD Display Stn Monochrome With Ili9341 COG IC
240×320 Dots TFT LCD Display Stn Monochrome With Ili9341 COG IC
240×320 Dots TFT LCD Display Stn Monochrome With Ili9341 COG IC
240×320 Dots TFT LCD Display Stn Monochrome With Ili9341 COG IC
240×320 Dots TFT LCD Display Stn Monochrome With Ili9341 COG IC
240×320 Dots TFT LCD Display Stn Monochrome With Ili9341 COG IC
240×320 Dots TFT LCD Display Stn Monochrome With Ili9341 COG IC
240×320 Dots TFT LCD Display Stn Monochrome With Ili9341 COG IC
Specifications
Brand Name :
Roya Display
Model Number :
RYTQ32NN01-01
Certification :
Rohs,ISO9001
Place of Origin :
China
MOQ :
500pcs
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union,
Supply Ability :
300K/M
Delivery Time :
15-20 Work Days
Packaging Details :
Cartons, Capboard, EPE, Blister Tray
LCD Size :
3.2'' TFT
Display Type :
262K TFT
Viewing Direction :
12 O'clock
Outline Dimension :
56.64X79.3X2.45mm
Viewing Area :
48.6X64.8mm
Driver IC :
Ili9341
Operation Voltage :
2.80-3.30V
Interface :
8080 16-Bit
Description

3.2inch TFT 240*320dots 262K LCD Display 40pin with Ili9341 COG IC

Product Description

Item Description
Product Name 3.2'' TFT 240*320 dots lcd display
LCD Type TFT
Model No. RYTQ32NN01-01
Outline Dimension (mm) 56.64X79.3X2.45mm
Viewing Area (mm) 48.6X64.8mm
Viewing Direction 12 O' clock
Driver IC ILI9341
Operation Temp -20º C~70º C
Storage Temp -30º C~80º C

240×320 Dots TFT LCD Display Stn Monochrome With Ili9341 COG IC

FAQ

Q: Can you customize the product? what do you need?

A: The product can be customized, but TFTlcd module has different tooling cost, which includes FPC,Touch Screen, Backlight , Bezel and so on.

Q: Can you provide drawings and related procedures?

A: We can provide drawings and procedures for customers to confirm.


Q: How to control the quality of products?
A: The company has a professional quality team, and all products are 100% inspected before shipment.

Q: How long is the warranty and service of the product?

A: Generally the warranty period is one year. It depends on different products.We guarantee our products to be free from manufacturer defects. Liability under this warranty is limited to the replacing of any product found to be defective under normal use.
