ROHS 1024*600 10.1 Inch Lcd Display , 600cd/m2 IPS LCD Module
ROHS 1024*600 10.1 Inch Lcd Display , 600cd/m2 IPS LCD Module
ROHS 1024*600 10.1 Inch Lcd Display , 600cd/m2 IPS LCD Module
ROHS 1024*600 10.1 Inch Lcd Display , 600cd/m2 IPS LCD Module
ROHS 1024*600 10.1 Inch Lcd Display , 600cd/m2 IPS LCD Module
ROHS 1024*600 10.1 Inch Lcd Display , 600cd/m2 IPS LCD Module
ROHS 1024*600 10.1 Inch Lcd Display , 600cd/m2 IPS LCD Module
ROHS 1024*600 10.1 Inch Lcd Display , 600cd/m2 IPS LCD Module
ROHS 1024*600 10.1 Inch Lcd Display , 600cd/m2 IPS LCD Module
ROHS 1024*600 10.1 Inch Lcd Display , 600cd/m2 IPS LCD Module
ROHS 1024*600 10.1 Inch Lcd Display , 600cd/m2 IPS LCD Module
ROHS 1024*600 10.1 Inch Lcd Display , 600cd/m2 IPS LCD Module
Specifications
Brand Name :
OEM
Model Number :
LX101003LX-03
Certification :
CE,FCC,ROHS
Place of Origin :
China
MOQ :
5pcs
Payment Terms :
T/T, Western Union
Supply Ability :
60Kpcs/month
Delivery Time :
5-8 working days
Packaging Details :
Standard export package
Type :
TFT
Resolution :
1024*600
Size :
10.1inch
Active Area :
222.72*125.28mm
Display mode :
Transmissive
Application :
Industrial , Consumer
Viewing Angle :
ALL o'clock
Typical Brightness :
600cd/m2
Touch Panel :
RTP or CTP Available
Outline dimension :
235.00*143.00*4.60mm
Description

10.1 inch led display panels 1024*600 IPS LCD modul tft lcd screen outdoor touch panel

Specification:

Items Descriptions
Part No. LCD TFT
Display Type: amorphous silicon TFT(a-Si TFT)
Display Colors: 16.7M
Resolution: 1024*600
Pixel Pitch: 0.2175 (H) x0.2088(V)
Viewing Direction: ALL o'clock
Controller IC: HX8282-A11+HX8696-A
Display Mode: Transmissive /Normally Black
Overall Size: 235.00*143.00*4.60mm
Active Area: 222.72*125.28mm
Luminance: 600cd/m2(typ)
Contrast: 500:1
Interface Type: RGB interface 24bit
Pin No.: 50
Pin Pitch: 0.5 Pitch
Input Voltage: VDD:3.3V, VGH:20V, VGL:-10V, AVDD:10.2V,VCOM:4.3V
Backlight Type and Color: LED backlight / white
Backlight: 42 LED, 14 groups in parallel, 3 LEDs in series in each group,Vf=9.6V, If=280mA
Operating Temperature: -20~70 °C
Storating Temperature: -30~80 °C

ROHS 1024*600 10.1 Inch Lcd Display , 600cd/m2 IPS LCD Module

ROHS 1024*600 10.1 Inch Lcd Display , 600cd/m2 IPS LCD Module

ROHS 1024*600 10.1 Inch Lcd Display , 600cd/m2 IPS LCD Module

ROHS 1024*600 10.1 Inch Lcd Display , 600cd/m2 IPS LCD Module

ROHS 1024*600 10.1 Inch Lcd Display , 600cd/m2 IPS LCD Module

ROHS 1024*600 10.1 Inch Lcd Display , 600cd/m2 IPS LCD Module

ROHS 1024*600 10.1 Inch Lcd Display , 600cd/m2 IPS LCD Module
