Full HD Resolutions Ultra Narrow Bezel Video Wall High Contrast Ratio Long Lifetimes
Full HD Resolutions Ultra Narrow Bezel Video Wall High Contrast Ratio Long Lifetimes
Specifications
Brand Name :
HBONY
Model Number :
HBY-PJ460P
Certification :
CE/CCC/FCC/ROHS/ISO9001
Place of Origin :
Guangdong , China
MOQ :
4 Pieces
Price :
Negotiation
Payment Terms :
L/C , T/T , Western Union , Paypal
Supply Ability :
3000 pieces per week
Delivery Time :
5-8 work days
Packaging Details :
Carton Box with PE Foam+wooden box
logo :
customized LED logo
Input :
HDMI,DVI,VGA,USB
Brand name :
HBONY
Panel Size :
46'' 47'' 49'' 55''
Application :
indoor
Material :
Metal
Lcd screen brands optional :
LG Samsung
Ultra Narrow Bezel optional :
1.7mm 1.8mm 3.5mm
Description

HBONY Lcd screen brands optional Ultra Narrow Bezel Video Wall

Features:

1. Samsung video wall panel with ultra-narrow bezel 1.7mm 1.8mm 3.5mm optional .

2. High color gamut ,high contrast ratio,display prefect pictures.

3. Adopt intelligent color adjustment technology,make sure the colour uniformity OF each screen,show vivid pictures.

4. LCD splicing unit adopts 5ms instant response time. No shadow or tail in picture.

5. Long life, stable operation, no burns, injuries, low maintenance costs

LCD video walls are designed to deliver even the largest images with stunning clarity. Virtually seamless bezel combined with LED light source brings you an excellent visual experience, in terms of resolution, brightness, contrast and viewing angles. The combination of rugged design and industrial-grade components can withstand the tough demands of industrial applications. Compared to conventional products, results show lower power consumption and long lifetimes.

High Resolution

Available in Full HD resolutions, HBONY’s high-resolution LCD video walls are ideal for demanding control room environments where image quality and accuracy are of utmost importance.

Wide Viewing Angle

HBONY’s LCD video wall design is further engineered to provide a wide viewing angle of 178°, resulting in superior image quality and outstanding color uniformity.

LED Light Source

HBONY’s LCD video walls are Eco friendly, as LED contains no mercury or other harmful materials. LED backlight reduce burn-in and ensure long life of the product with lower power consumption.

Item Parameters
Model HBY-PJ460P
Panel LTI460HN11/SAMSUNG
Panel type a-Si TFT-LCD,lcd screen
Panel size 1021.98*576.57mm
Backlight LED
Resolution 1920*1080
Display mode normal black display,transmission-type
Display area 1018.28*572.87mm
Pixel spacing 0.4845*0.4845
surface treatment Haze 44%
Aspect ratio 16:9
Panel brightness 500cd/m2
Contrast ratio 4000:1
Display color 16.7M
Response time 8ms
Viewing angle 178°
Refresh frequency 60HZ
Frequency 50Hz/60Hz/70Hz
3D noise reduction YES
Video noise reduction YES
3D comb filter YES
Multimedia interface 1 HDMI interface
D-SUB interface 1 VGA interface
Digital video interface 1 DVI interface
Composite video input 2 BNC interface
Composite video output 1 BNC
Serial control input 1 RJ45(RS-232)
Serial control output RS-232(2 output)
Address code switch Set the ID address of the screen
Video format PAL/NTSC/SECAM
life span 60000(minimum) hour
Cooling system Ultra quiet dual fan cooling, with temperature control function
Material of housing Rugged metal shell
Menu language Chinese/English (optional)
Signal format NTSC,PAL,480P,576P,720P,1080I,1080P
Standby power loss ＜1W
Total consumption ≤230W
Input voltage AC100V-240V 50/60Hz
Working temperature —20°~65°
Installation mode Wall-installation, embedded, floor cabinet, hoisting, TV cabinet
Weight /
Cabinet material All steel frame, aluminum, screen frame decorative (user optional material)
Dual packing outersize 1150×355×695mm
Control software MultiScreenGraphics
