YS-HX542 Two Working Platform 4-Axis Automatic Soldering Machine Programmable With English Touch Screen
YS-HX542 Two Working Platform 4-Axis Automatic Soldering Machine Programmable With English Touch Screen
Specifications
Brand Name :
RKENS
Model Number :
YS-HX542
Place of Origin :
China
Name :
Two Working Platform 4-Axis Automatic Soldering Machine
Working Table :
2
Description

YS-HX542 Two Working Platform 4-Axis Automatic Soldering Machine Programmable With English Touch Screen

Intro:

YS-HX542 is a programmable auto soldering machine. With LCD touch screeen, operator can easily program the soldering routes. the soldering size, tin quantity, soldering shape, all these can be set.

Parameters:

Basic parameters Specification&Model YS-HX542
Outside dimensions 680(L)*750(W)*850(H)(mm)
Weight 63Kg
Using enviroment Power source AC 220V/50Hz
Air Clean0.4~0.6kpa
Out connection tube diameter 8mm
Working environment 0-40℃ Humidity 20-90% (no condensation)
Allow minimum desktop size 800mm×800mm
Temperature Control System Heating vortex 200W/300W
Range of temperature 180-450℃
Number of irons 1
Motion System Number of axes 5
Drive system Stepper motor, synchronous belt
Workpiece size X-axis 200
Y-axis 400
Z-axis 100
U-axis 360°
Maximum speed X/Y-axis 500mm/s
Z-axis 250mm/s
Repeatability accuracy X/Y/Z-axis ±0.02mm
Maximum weight 10Kg
Program Mode Teaching format Offline/Online
Language Chinese/English
Number of programs 9999
Welding parameter range Use tin wire range (diameter) 0.6mm--1.5mm
Single point welding time (related to the size of the solder joint) 0.2s--100s
Features:

Advantages:

1. Chinese/English input, easy to learn and easy to understand, without an external guidance device, more convenient, simple and high speed precision.

2. With points, lines, arcs, circles, irregularly curved continuous input procedures and any position welding.

3. Solder feeding amount is adjustable. With temperature adjusting function

4. To edit the continuous and rapid spot, set change interval to achieve repeated welding solution, increasing operational efficiency.

5. High speed precision stepping motor makes location more accurately

6. Adjust the temperature and time and solder feeding speed, control the amount of feeding solder, meets high quality welding

7. According to a client's product, you can choose to assemble multiple spot welding, more suitable for the arrangement of standard products.

8. Can preview edit tracks and adjust accordingly.

9. Welding path can be called at any time, weld track store multiple files, no need repeated edit.

10. Equipped with computer controlled motion, software programming, multiple operations can be realized.

Soldering machine details

YS-HX542 Two Working Platform 4-Axis Automatic Soldering Machine Programmable With English Touch Screen

Applications

YS-HX542 Two Working Platform 4-Axis Automatic Soldering Machine Programmable With English Touch Screen
