Factory direct supply Anti-explosion trailer Electric flatbed ladel transfer truck
Factory direct supply Anti-explosion trailer Electric flatbed ladel transfer truck
Factory direct supply Anti-explosion trailer Electric flatbed ladel transfer truck
Factory direct supply Anti-explosion trailer Electric flatbed ladel transfer truck
Factory direct supply Anti-explosion trailer Electric flatbed ladel transfer truck
Factory direct supply Anti-explosion trailer Electric flatbed ladel transfer truck
Factory direct supply Anti-explosion trailer Electric flatbed ladel transfer truck
Factory direct supply Anti-explosion trailer Electric flatbed ladel transfer truck
Specifications
Brand Name :
Topleader
Model Number :
KPT
Certification :
CE,ISO9000
Place of Origin :
China
MOQ :
1 set
Price :
$8000
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
600 sets/year
Delivery Time :
30-40 days after receive your prepayment
Packaging Details :
The whole cart will be packed by the tarp, the parts will be packed by polywood case.
Product name :
Factory direct supply Anti-explosion trailer Electric flatbed ladel transfer truck
Power supply :
Battery powered
Material :
steel
Load capacity :
1-300T
Running speed :
0-20m/min
Application :
Factory ,warehouse and working line
Warranty :
1 year
Color :
customized
OEM :
Accepted
Description

Factory direct supply Anti-explosion trailer Electric flatbed ladel transfer truck

Brief Introduction - Factory direct supply flatbed ladel transfer truck

KPX Series Anti-explosion trailer Electric flatbed ladel transfer truck are battery powered. The steel coil handling can be used both on the “S” and arc-shaped railways. The KPX series are more safe and flexible and running distance is not limited. It has no strict requirement for the construction of the railway. Factory direct supply Anti-explosion trailer Electric flatbed ladel transfer truck is suitable to be used in the long distance transportation, and it is a great solution of industry heavy materials handling.
Factory direct supply Anti-explosion trailer Electric flatbed ladel transfer truck

Advantages - Anti-explosion trailer Electric ladel transfer truck

  • The Factory direct supply Anti-explosion trailer Electric flatbed ladel transfer truck powwered by battery is Travelling steady and durable;
  • Running on the straight railways or on the ‘S’ and arc-shaped railways to carry many material;
  • The Electric flatbed ladel transfer truck can be used in the ferry condition and flammable, explosive environment;
  • The Factory direct supply Anti-explosion trailer is suitable for the long running distance transportation;
  • The hydraulic lifting device can be installed on Electric flatbed ladel transfer truck;
  • The running distance is unlimited;
  • The Factory direct supply Anti-explosion trailer has features of Stable start, big starting power, small impact to the gear reducer, low voltage, long lifetime and so on.

Factory direct supply Anti-explosion trailer Electric flatbed ladel transfer truck

Working principle - Factory direct supply flatbed ladel transfer truck

KPX Series Electric flatbed ladel transfer truck are battery powered. The battery are installed in the carts. The battery supplies electricity to the DC motor through the electrical control system. We use this principle to make the car start, stop, move forward, move backward, adjust the speed etc.

Factory direct supply Anti-explosion trailer Electric flatbed ladel transfer truck

Application - Factory direct supply Anti-explosion trailer

The Anti-explosion trailer Electric flatbed ladel transfer truck is applied to transfer steel ladles or steel scrap ladle in steel factory and meturallgy plant. Generally the load capacity is large, can reach to 150 tons. It is commonly applied in steel plant, mechallurgy industry, aluminum factory, plastic pipes factory, etc. to transfer rounded material, from producing line to store.

Factory direct supply Anti-explosion trailer Electric flatbed ladel transfer truck

Parameters - Factory direct supply Electric flatbed ladel transfer truck

Model
 KPT-2T KPT-10T KPT-20T KPT-30T KPT-50T KPT-63T KPT-150T
Rated load (T) 2 10 20 30 50 63 150
Table size length(L) 2000 3600 4000 4500 5500 5600 10000
Width(W) 1500 2000 2200 2200 2500 2500 3000
Height(H) 450 500 550 600 650 700 1200
Wheel Base (mm) 1200 2600 2800 3200 4200 4300 7000
Rail Inner Gauge (mm) 1200 1435 1435 1435 1435 1435 2000
Wheel Diameter(mm) Φ270 Φ300 Φ350 Φ400 Φ500 Φ600 Φ600
Wheel Quantity 4 4 4 4 4 4 8
Ground Clearance (mm) 50 50 50 50 50 75 75
Running speed (min) 0-25 0-25 0-20 0-20 0-20 0-20 0-18
Motor Power (Kw) 1 1.6 2.2 3.5 5 6.3 15
Battery Capacity(Ah) 180 160 180 250 330 400 600
Battery Voltage(V) 24 48 48 48 48 48 72
Running Time When Full Load 4.32 4.8 4 3.5 3.3 3 2.9
Running Distance for one Charge(Km) 6.5 7.2 4.8 4.2 4 3.6 3.2
Max Wheel Load (KN) 14.4 42.6 77.7 110.4 174 221.4 265.2
Reference Weight (t) 2.8 4.2 5.9 6.8 8 10.8 26.8
Recommended Rail Model P15 P18 P24 P38 P43 P50 QU100

Packing & Delivery - Anti-explosion trailer Electric flatbed ladel transfer truck

The Factory direct supply Anti-explosion trailer Electric flatbed ladel transfer truck will be packed by the tarp, the parts will be packed by polywood case.

Factory direct supply Anti-explosion trailer Electric flatbed ladel transfer truck
