Steel Industry Automatic Transfer Carriage Rail Guided Powered Trolley With Rollers
Steel Industry Automatic Transfer Carriage Rail Guided Powered Trolley With Rollers
Steel Industry Automatic Transfer Carriage Rail Guided Powered Trolley With Rollers
Steel Industry Automatic Transfer Carriage Rail Guided Powered Trolley With Rollers
Steel Industry Automatic Transfer Carriage Rail Guided Powered Trolley With Rollers
Steel Industry Automatic Transfer Carriage Rail Guided Powered Trolley With Rollers
Steel Industry Automatic Transfer Carriage Rail Guided Powered Trolley With Rollers
Steel Industry Automatic Transfer Carriage Rail Guided Powered Trolley With Rollers
Specifications
Brand Name :
Topleader
Model Number :
KPX
Certification :
CE,ISO9000
Place of Origin :
China
MOQ :
1 set
Price :
$5000-$12000
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
600 sets/year
Delivery Time :
30-40 days after receive your prepayment
Packaging Details :
The whole cart will be packed by the tarp, the parts will be packed by polywood case.
Product name :
Steel Industry Automatic Transfer Carriage Rail Guided Powered Trolley With Rollers
Power supply :
Battery powered
Material :
steel
Load capacity :
1-300T
Running speed :
0-20m/min
Application :
Factory ,warehouse and working line
Warranty :
1 year
Color :
customized
OEM :
Accepted
Description

Steel Industry Automatic Transfer Carriage Rail Guided Powered Trolley With Rollers

Introduction --- Rail Guided Powered Trolley

KPX series rail guided powered trolley powered by the storage battery. It has been installed in the transfer trolley, battery directly to the DC traction power supply. DC motors and AC motors are easily damaged in comparison, start torque, strong overload capability advantages.

Compare wtih KPJ, KPD series electric transfer trolley, it is of the greater flexibility in security and mobility. The running distance is not limited and without demand of rail isolation,so the construction is convenient and the cost is low.

This type of electric transfer trolley can provide the following optional parts for the customer to further improve the efficiency of (1) maintenance-free battery (2) import Promise speed control, dual speed control (3) the import of industrial wireless remote control

Steel Industry Automatic Transfer Carriage Rail Guided Powered Trolley With Rollers

Rail Guided Powered Trolley Details

Steel Industry Automatic Transfer Carriage Rail Guided Powered Trolley With Rollers

Parameter List --- Rail Guided Powered Trolley

Model

KPX-2T

KPX-10T

KPX-20T

KPX-30T

KPX-50T

KPX-63T

KPX-150T

Rated load (T)

2

10

20

30

50

63

150

Table size

length(L)

2000

3600

4000

4500

5500

5600

10000

Width(W)

1500

2000

2200

2200

2500

2500

3000

Height(H)

450

500

550

600

650

700

1200

Wheel Base (mm)

1200

2600

2800

3200

4200

4300

7000

Rail Inner Gauge (mm)

1200

1435

1435

1435

1435

1435

2000

Wheel Diameter(mm)

Φ270

Φ300

Φ350

Φ400

Φ500

Φ600

Φ600

Wheel Quantity

4

4

4

4

4

4

8

Ground Clearance (mm)

50

50

50

50

50

75

75

Running speed (min)

0-25

0-25

0-20

0-20

0-20

0-20

0-18

Motor Power (Kw)

1

1.6

2.2

3.5

5

6.3

15

Battery Capacity(Ah)

180

160

180

250

330

400

600

Battery Voltage(V)

24

48

48

48

48

48

72

Running Time When Full Load

4.32

4.8

4

3.5

3.3

3

2.9

Running Distance for one Charge(Km)

6.5

7.2

4.8

4.2

4

3.6

3.2

Max Wheel Load (KN)

14.4

42.6

77.7

110.4

174

221.4

265.2

Reference Weight (t)

2.8

4.2

5.9

6.8

8

10.8

26.8

Recommended Rail Model

P15

P18

P24

P38

P43

P50

QU100

Application --- Rail Guided Powered Trolley

The rail guided powered trolley is mainly applied in assembly line(ring production line, loop production line), metallurgy industry (steel ladle), warehouse transport, ship industry (maintenance, assemble, container transport), workpiece transport in workshop, lathe transport, steel factory(steel billet, steel plate, steel coil, steel pipe, section steel, steel structure), construction(bridge, simple building, concrete, concrete column), petroleum industry(oil pump, sucker rod and parts), energy(polycrystalline silicon, generator, windmill), chemical industry(electrolytic cell, retort etc), railway(rail maintenance, rail welding, train tractor).

Steel Industry Automatic Transfer Carriage Rail Guided Powered Trolley With Rollers

Delivery & Package --- Rail Guided Powered Trolley

Steel Industry Automatic Transfer Carriage Rail Guided Powered Trolley With Rollers

Customer Visit --- Rail Guided Powered Trolley

Steel Industry Automatic Transfer Carriage Rail Guided Powered Trolley With Rollers

Processing --- Rail Guided Powered Trolley

Steel Industry Automatic Transfer Carriage Rail Guided Powered Trolley With Rollers

Our After-Sale Service

Our company promises to “produce high-quality products, provide satisfactory services, and strive to create the first brand of transfer cart”. In order to ensure that your interests are realized, we have established a rapid quality information feedback system and a technically sturdy and well-resourced technical service team. We are enthusiastic to provide you with the following services:

Our company promises that the designed safety factor of the transfer cart loading should not be lower than 120%. According to user's specific conditions, free design auxiliary equipment or foundation drawings, and free provide technical services or drawing. Free send personal to work site install or debug or guide the installation. While promptly solving the quality problems of the sold products, the after-sales service personnel are obliged to provide users with technical consultation, technical training and answering questions relating to other products at no cost.
