Specifications
Brand Name :
Topleader
Model Number :
KPD
Certification :
CE,ISO9000
Place of Origin :
China
MOQ :
1 set
Price :
$5000-$12000
Payment Terms :
L/C, T/T
Supply Ability :
600 sets/year
Delivery Time :
30-40 days after receive your prepayment
Packaging Details :
The whole steel plate handling wagon will be packed by the tarp, the parts will be packed by polywood case.
Product name :
200 Ton Quarry Factory Crane Rail Bar Transport Steel Plate Handling Wagon
Power supply :
low voltage rail
Key Words :
steel plate handling wagon
Load capacity :
1-300T
Running speed :
20m/min
Color :
Customized
Warranty :
12 months
Application :
steel plant workshop, warehouse, production line
OEM :
Accepted
Description

200 Ton Quarry Factory Crane Rail Bar Transport Steel Plate Handling Wagon

Steel Plate Handling Wagon Introduce:

The steel plate handling wagon get electricity from the rails which is insulated, because it is added with insulated materials. The electricity is passed through wheels to the steel plate handling wagon. High electricity is transformed by transformer in to low safe voltage. If running distance is beyond 70 meters, extra transformers are added.

200 Ton Quarry Factory Crane Rail Bar Transport Steel Plate Handling Wagon

Advantage of Steel Plate Handling Wagon:


1.safe and flexible
2.adjustable speed
3.low noise level
4.save cost
5.eco-friendly
6.easy operation
7.easy maintenance
8.high using frequency

200 Ton Quarry Factory Crane Rail Bar Transport Steel Plate Handling Wagon

Steel Plate Handling Wagon parameter:

Model
 KPD-2T KPD-5T KPD-10T KPD-20T KPD-30T KPD-40T KPD-50T KPD-63T
Rated load (T) 2 5 10 20 30 40 50 63
Table size length(L) 2000 3500 3600 4000 4500 5000 5500 5600
Width(W) 1500 2000 2000 2200 2200 2500 2500 2500
Height(H) 450 450 500 550 600 650 650 750
Wheel Base (mm) 1200 2500 2600 2800 3200 3800 4200 4300
Rail Inner Gauge (mm) 1200 1435 1435 1435 1435 1435 1435 1435
Wheel Diameter(mm) Φ270 Φ300 Φ300 Φ350 Φ400 Φ500 Φ500 Φ600
Wheel Quantity(Nos) 4 4 4 4 4 4 4 4
Ground Clearance (mm) 50 50 50 50 50 50 50 75
Running speed (m/min) 0-25 0-25 0-25 0-20 0-20 0-20 0-20 0-20
Motor Power (Kw) 1 1.2 1.6 2.2 3.5 4 5 6.3
Transformer Power (KVA) 3 5 5 6.8 10 10 10 20
Transformer Quantity (Pcs) 1 1 1 1 1 1 1 1
Running Distance (m) 80 80 80 80 80 60 50 50
Max Wheel Load (KN) 14.4 25.8 42.6 77.7 110.4 142.8 174 221.4
Reference Weight (T) 2.8 3.6 4.2 5.9 6.8 7.6 8 10.8
Recommended Rail Model P15 P18 P18 P24 P38 P43 P43 P50


Steel Plate Handling Wagon application


The steel plate handling wagon on rail is mainly applied in metallurgy industry (steel ladle), warehouse transport, ship industry (maintenance, assemble, container transport), workpiece transport in workshop, lathe transport, steel factory (steel billet, steel plate, steel coil, steel pipe, section steel, steel structure).

200 Ton Quarry Factory Crane Rail Bar Transport Steel Plate Handling Wagon

Customer visit:

200 Ton Quarry Factory Crane Rail Bar Transport Steel Plate Handling Wagon

Our customer feedback:


200 Ton Quarry Factory Crane Rail Bar Transport Steel Plate Handling Wagon

Processing flow of Steel Plate Handling Wagon:

200 Ton Quarry Factory Crane Rail Bar Transport Steel Plate Handling Wagon

Our company introduction:

Xinxiang New Leader Machinery Manufcturing Co., Ltd has won the great fame by its clients with the excellent design and advanced technology of transfer carts, besides that, it is also believed to be the long cooperate partners by its customers with the perfect after-sale service.
We can produce 1-500 ton range of various tonnage of KPD rail low voltage series, KPJ cable reel series, KPC safety sliding line series, KPX battery powered series, BWP rubber wheel transfer cart series, KPT towed cable series, KP non-power type seven series which including turning electric flat car, trackless electric flat car, ladle car, ferry electric flat car, hydraulic lifting electric transfer car, electric winch, rail wheel and so on more than 90 products.
