Specifications
Brand Name :
Topleader
Model Number :
KPX-20T block transfer car
Certification :
CE,ISO9000
Place of Origin :
China
MOQ :
1 set
Price :
$7000-$12000
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
600 sets/year
Delivery Time :
30-40 days after your prepayment
Packaging Details :
The whole cart will be packed by the tarp, the parts will be packed by polywood case.
Product name :
Oversea service industry apply material handling block transfer car on rail
Power supply :
Storage battery
Material :
steel
Load capacity :
1-300T
Running speed :
0-20m/min
Application :
Factory ,warehouse and working line
Warranty :
1 year
Color :
customized
OEM :
Accepted
Description


Oversea service industry apply material handling block transfer car on rail

Working principle of block transfer car
KPX material handling block transfer car is powered by battery. The battery supply power to the DC motor, which is installed inside of cart body. Through the order of start, stop,forward,back,speed governing,etc, electrical control system command the order to DC motor to drive transfer cart working.

Description of block transfer car

The whole block transfer car is composed of motor, reducer, electric appliance and wheels. Due to more parts, compared with other carts, it has large size. But it travels flexibly.

The block transfer car is our company’s patented products which can run on the rails ‘S’, arc-shaped and so on.The turning radius is small and the turning is stable and flexible.

Our superiority is that we don’t use the traditional complex mechanical structure for the turning and controlling. The thing we do is to optimize structure of the driving parts. By this method, the cost can be greatly reduced, so does the maintenance work.

Oversea service industry apply material handling block transfer car on rail Oversea service industry apply material handling block transfer car on rail Oversea service industry apply material handling block transfer car on rail
Oversea service industry apply material handling block transfer car on rail Oversea service industry apply material handling block transfer car on rail Oversea service industry apply material handling block transfer car on rail


Application of block transfer car

This kind of block transfer car is commonly applied in factory or warehouse to transfer heavy materials, such as steel workpiecs, machine parts etc.
Oversea service industry apply material handling block transfer car on rail
Oversea service industry apply material handling block transfer car on rail
Oversea service industry apply material handling block transfer car on rail

Technical parameters of block transfer car

ModelKPX-2TKPX-10TKPX-20TKPX-30TKPX-50TKPX-63TKPX-150T
Rated load (T)21020305063150
Table sizelength(L)20003600400045005500560010000
Width(W)1500200022002200250025003000
Height(H)4505005506006507001200
Wheel Base (mm)1200260028003200420043007000
Rail Inner Gauge (mm)1200143514351435143514352000
Wheel Diameter(mm)Φ270Φ300Φ350Φ400Φ500Φ600Φ600
Wheel Quantity4444448
Ground Clearance (mm)50505050507575
Running speed (min)0-250-250-200-200-200-200-18
Motor Power (Kw)11.62.23.556.315
Running Time When Full Load4.324.843.53.332.9
Running Distance for one Charge(Km)6.57.24.84.243.63.2
Max Wheel Load (KN)14.442.677.7110.4174221.4265.2
Reference Weight (t)2.84.25.96.8810.826.8
Recommended Rail ModelP15P18P24P38P43P50QU100


Manufacturing of block transfer car

Oversea service industry apply material handling block transfer car on rail
Delivery of block transfer car

Oversea service industry apply material handling block transfer car on rail

Customer visit in our factory from world wide

Oversea service industry apply material handling block transfer car on rail
Oversea service industry apply material handling block transfer car on rail

Block transfer car applied at site in customers' factory


Oversea service industry apply material handling block transfer car on rail

After-sale service

  • Our commitment: The load bearing safety factor of the trolley is no less than 120%.

  • Freely design the auxiliary device or foundation drawing, and offer the technical service and drawing material.

  • 16 hours engineering service and 24 hours internet service for our customers.

  • During the warranty period, if our products can't work normally, we can support you repair technology or replace relevant parts for you within 24 hours.

  • Solving the quality problem within 24 hours, serious attitude from beginning to end. Value the reputation and Preserve the image of our company.
