Specifications
Brand Name :
Topleader
Model Number :
KPX
Certification :
CE,ISO9000
Place of Origin :
China
MOQ :
1 set
Price :
$7000-$12000
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
600 sets/year
Delivery Time :
30-40 days after your prepayment
Packaging Details :
The whole cart will be packed by the tarp, the parts will be packed by polywood case.
Product name :
Heavy Duty Hydraulic lift Steel Coil Car Transfer System with Safety Sensors for Material Handling
Power supply :
Battery powered
Material :
steel Q235
Load capacity :
1-300T
Running speed :
0-20m/min
Application :
Factory ,warehouse and working line
Warranty :
1 year
Color :
Red, yellow, blue or customized
OEM :
Accepted
Description

Heavy Duty Hydraulic lift Steel Coil Car Transfer System with Safety Sensors for Material Handling

Steel coil car transfer system Introduce

The Heavy Duty Hydraulic lift Steel Coil Car Transfer System with Safety Sensors for Material Handling is an electric driven material handling transfer car. These steel coil transfer cars the design and the deck configuration can be customised to suit specific requirements with capacities up to 500 tonne.

Heavy Duty Hydraulic lift Steel Coil Car Transfer System with Safety Sensors for Material Handling

Coil Transfer Car Parts

Heavy Duty Hydraulic lift Steel Coil Car Transfer System with Safety Sensors for Material Handling

Parameter of heavy duty transfer car

Model

KPX-2T

KPX-10T

KPX-20T

KPX-30T

KPX-50T

KPX-63T

KPX-150T

Rated load (T)

2

10

20

30

50

63

150

Table size

length(L)

2000

3600

4000

4500

5500

5600

10000

Width(W)

1500

2000

2200

2200

2500

2500

3000

Height(H)

450

500

550

600

650

700

1200

Wheel Base (mm)

1200

2600

2800

3200

4200

4300

7000

Rail Inner Gauge (mm)

1200

1435

1435

1435

1435

1435

2000

Wheel Diameter(mm)

Φ270

Φ300

Φ350

Φ400

Φ500

Φ600

Φ600

Wheel Quantity

4

4

4

4

4

4

8

Ground Clearance (mm)

50

50

50

50

50

75

75

Running speed (min)

0-25

0-25

0-20

0-20

0-20

0-20

0-18

Motor Power (Kw)

1

1.6

2.2

3.5

5

6.3

15

Battery Capacity(Ah)

180

160

180

250

330

400

600

Battery Voltage(V)

24

48

48

48

48

48

72

Running Time When Full Load

4.32

4.8

4

3.5

3.3

3

2.9

Running Distance for one Charge(Km)

6.5

7.2

4.8

4.2

4

3.6

3.2

Max Wheel Load (KN)

14.4

42.6

77.7

110.4

174

221.4

265.2

Reference Weight (t)

2.8

4.2

5.9

6.8

8

10.8

26.8

Recommended Rail Model

P15

P18

P24

P38

P43

P50

QU100

Application

Die handling – Portable machine base – Assembly mount – Metal coil transporter – Heavy equipment transporter with lift deck – Structural steel transporter – Shuttle cart for pipe – Precast concrete production cart – Portable base for jib arm with spreader beam

Heavy Duty Hydraulic lift Steel Coil Car Transfer System with Safety Sensors for Material Handling

Customer Visit

Heavy Duty Hydraulic lift Steel Coil Car Transfer System with Safety Sensors for Material Handling

Packaging & Delivery

Heavy Duty Hydraulic lift Steel Coil Car Transfer System with Safety Sensors for Material Handling

What Are The Advantages of Using a Transfer Cart?


For smaller loads, manual transfer carts can be dedicated to specific work place activities such as shuttling materials. This often makes the carts more available for use. Transfer carts are more accommodating for moving long loads through restrictive passage ways or doorways. For heavier loads transfer carts are an excellent affordable choice for their ability to handle heavy loads. Transfer carts are compact in design and work well in areas with limited floor area. Another advantage over lift trucks is how the cart deck can be customized to suit specific loads.

Heavy Duty Hydraulic lift Steel Coil Car Transfer System with Safety Sensors for Material Handling
