Specifications
Brand Name :
Topleader
Model Number :
KPX-30T mold cart
Certification :
CE,ISO9000
Place of Origin :
China
MOQ :
1 set
Price :
$7000-$12000
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
600 sets/year
Delivery Time :
30-40 days after your prepayment
Packaging Details :
The whole mold cart will be packed by the tarp, the parts will be packed by polywood case.
Product name :
Precast concrete factory use mold cart for heacy material transporting from bay to bay
Power supply :
Storage battery
Material :
steel
Load capacity :
1-300T
Running speed :
0-20m/min
Application :
Factory ,warehouse and working line
Warranty :
1 year
Color :
customized
OEM :
Accepted
Description

Precast concrete factory use mold cart for heacy material transporting from bay to bay


Working principle of mold cart


KPX mold cart is powered by battery. It is used to transfer molds. The battery supply power to the DC motor, which is installed inside of cart body. Through the order of start, stop, forward, back, speed governing, etc, electrical control system command the order to DC motor to drive transfer cart working.


Precast concrete factory use mold cart for heacy material transporting from bay to bay


Description of mold cart


The whole mold cart is composed of motor, reducer, electric appliance and wheels. Due to more parts, compared with other carts, it has large size. But it travels flexibly.

The driving wheel and load wheel of trackless car is high strength PU wheel. It is wear-resistance, and has low maintain cost.

The functions of the mold cart including 360 degree turning, go forward and backward,turn left and right, adjust speed button, indicator light, electric indicator light and other control buttons.


Precast concrete factory use mold cart for heacy material transporting from bay to bay Precast concrete factory use mold cart for heacy material transporting from bay to bay Precast concrete factory use mold cart for heacy material transporting from bay to bay
Precast concrete factory use mold cart for heacy material transporting from bay to bay Precast concrete factory use mold cart for heacy material transporting from bay to bay Precast concrete factory use mold cart for heacy material transporting from bay to bay


Application of mold cart


This kind of mold cart is commonly applied in factory or warehouse to transfer heavy materials, such as steel workpiecs, machine parts, etc.


Precast concrete factory use mold cart for heacy material transporting from bay to bay Precast concrete factory use mold cart for heacy material transporting from bay to bay
Precast concrete factory use mold cart for heacy material transporting from bay to bay Precast concrete factory use mold cart for heacy material transporting from bay to bay

Technical parameters of mold cart


Model

KPX-2T

KPX-10T

KPX-20T

KPX-30T

KPX-50T

KPX-63T

KPX-150T

Rated load (T)

2

10

20

30

50

63

150

Table size

length(L)

2000

3600

4000

4500

5500

5600

10000

Width(W)

1500

2000

2200

2200

2500

2500

3000

Height(H)

450

500

550

600

650

700

1200

Wheel Base (mm)

1200

2600

2800

3200

4200

4300

7000

Rail Inner Gauge (mm)

1200

1435

1435

1435

1435

1435

2000

Wheel Diameter(mm)

Φ270

Φ300

Φ350

Φ400

Φ500

Φ600

Φ600

Wheel Quantity

4

4

4

4

4

4

8

Ground Clearance (mm)

50

50

50

50

50

75

75

Running speed (min)

0-25

0-25

0-20

0-20

0-20

0-20

0-18

Motor Power (Kw)

1

1.6

2.2

3.5

5

6.3

15

Running Time When Full Load

4.32

4.8

4

3.5

3.3

3

2.9

Running Distance for one Charge(Km)

6.5

7.2

4.8

4.2

4

3.6

3.2

Max Wheel Load (KN)

14.4

42.6

77.7

110.4

174

221.4

265.2

Reference Weight (t)

2.8

4.2

5.9

6.8

8

10.8

26.8

Recommended Rail Model

P15

P18

P24

P38

P43

P50

QU100


Manufacturing of mold cart


Precast concrete factory use mold cart for heacy material transporting from bay to bay


Delivery of mold dart



Precast concrete factory use mold cart for heacy material transporting from bay to bay


Customer visit in our factory from world wide


Precast concrete factory use mold cart for heacy material transporting from bay to bay


Rail transfer cart applied at site in customers' factory



Precast concrete factory use mold cart for heacy material transporting from bay to bay


After-sale service

  • Our commitment: The load bearing safety factor of the trolley is no less than 120%.

  • Freely design the auxiliary device or foundation drawing, and offer the technical service and drawing material.

  • 16 hours engineering service and 24 hours internet service for our customers.

  • During the warranty period, if our products can't work normally, we can support you repair technology or replace relevant parts for you within 24 hours.

  • Solving the quality problem within 24 hours, serious attitude from beginning to end. Value the reputation and Preserve the image of our company.
