30t Trackless Battery Platform Transfer Cart For Foundry Plant Shaft Handling
30t Trackless Battery Platform Transfer Cart For Foundry Plant Shaft Handling
30t Trackless Battery Platform Transfer Cart For Foundry Plant Shaft Handling
30t Trackless Battery Platform Transfer Cart For Foundry Plant Shaft Handling
30t Trackless Battery Platform Transfer Cart For Foundry Plant Shaft Handling
30t Trackless Battery Platform Transfer Cart For Foundry Plant Shaft Handling
30t Trackless Battery Platform Transfer Cart For Foundry Plant Shaft Handling
30t Trackless Battery Platform Transfer Cart For Foundry Plant Shaft Handling
Specifications
Brand Name :
Topleader
Model Number :
BWP-30T
Certification :
CE,ISO9000
Place of Origin :
China
MOQ :
1 set
Price :
$7000-$12000
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
600 sets/year
Delivery Time :
50 days after your prepayment
Packaging Details :
The whole transfer cart will be packed by the tarp, the parts will be packed by polywood case.
Product name :
30t Trackless Battery Platform Transfer Cart For Foundry Plant Shaft Handling
Power supply :
Storage battery
Material :
steel
Load capacity :
1-100T
Running speed :
0-20m/min
Application :
Factory ,warehouse and working line
Warranty :
1 year
Color :
customized
OEM :
Accepted
Description

30t Trackless battery platform Transfer Cart for foundry plant shaft handling


Working Principle of Trackless Battery Platform Transfer Cart


Trackless battery platform transfer cart is powered by storage battery. The battery is installed in the trackless platform and we also equip intelligent charger for it. The battery platform transfer cart is controlled to go forward, backward, turn left, turn right, adjust speed through PLC and speed controller.


30t Trackless Battery Platform Transfer Cart For Foundry Plant Shaft Handling


Description of Trackless Battery Platform Transfer Cart

The whole battery platform transfer cart is composed of motor, reducer, electric appliance and wheels. Due to more parts, compared with other carts, it has large size. But it travels flexibly.

The driving wheel and load wheel of trackless cart is high strength PU wheel. It is wear-resistance, and has low maintain cost.

The functions of the trackless battery platform transfer cart including 360 degree turning, go forward and backward,turn left and right, adjust speed button, indicator light, electric indicator light and other control buttons.


30t Trackless Battery Platform Transfer Cart For Foundry Plant Shaft Handling


Application of Trackless Battery Platform Transfer Cart

This kind of trackless battery platform transfer cart is commonly applied in factory or warehouse to transfer heavy materials, such as steel workpiecs, machine parts, etc.


30t Trackless Battery Platform Transfer Cart For Foundry Plant Shaft Handling


Technical Parameters of Trackless Battery Platform Transfer Cart

Model BWP-30T
Rated Load(t) 30t
Impacted rated load(t) 32
structure of frame steel plates welded beam structure
Thickness of the steel plate 12
Cart weight(t) 6
Wheel load(t) 7.7
Ground requirement cement ground
Table size(mm) 5000x2200
Height of the whole cart(mm) 650
Space from the ground(mm) 50
Wheels distance 1700
Axles distance 4300
Turning radius(mm) 4300
Turning type turning while driving without stop
Control method for turning control button
Turning structure mechanical
Wheel diameter Ф400/4
Wheel quality polyurethane wheels
Running speed(m/min) 0-12
Brake principle electric magnetic force
Operation method with wire or no wire
Charger motor's installation installed on cart
Function of charger motor automatic charging
Warning equipment sound and light lamp

Advantage of Trackless Battery Platform Transfer Cart

The motor adopts DC traction motor, the protection grade: IP44. Compact structure, large overload capacity, long service life. Excellent load performance, good low-speed performance, big starting torque, small starting current. It is suitable for frequent start and saves electricity. The motor runs with high efficiency in the range of all speeds. The motor adopts imported high-speed bearing retaining oil, and it is of free maintenance, high reliability and long service life.

30t Trackless Battery Platform Transfer Cart For Foundry Plant Shaft Handling


Manufacturing of Trackless Battery Platform Transfer Cart


30t Trackless Battery Platform Transfer Cart For Foundry Plant Shaft Handling


Delivery of Trackless Battery Platform Transfer Cart


30t Trackless Battery Platform Transfer Cart For Foundry Plant Shaft Handling


Customer visit in our factory from world wide


30t Trackless Battery Platform Transfer Cart For Foundry Plant Shaft Handling
30t Trackless Battery Platform Transfer Cart For Foundry Plant Shaft Handling


After-sale service

  • Our commitment: The load bearing safety factor of the trolley is no less than 120%.

  • Freely design the auxiliary device or foundation drawing, and offer the technical service and drawing material.

  • 16 hours engineering service and 24 hours internet service for our customers.

  • During the warranty period, if our products can't work normally, we can support you repair technology or replace relevant parts for you within 24 hours.

  • Solving the quality problem within 24 hours, serious attitude from beginning to end. Value the reputation and Preserve the image of our company.

  • 30t Trackless Battery Platform Transfer Cart For Foundry Plant Shaft Handling
