10t capacity electric rubber wheel transfer cart for Malaysia coil handling
10t capacity electric rubber wheel transfer cart for Malaysia coil handling
10t capacity electric rubber wheel transfer cart for Malaysia coil handling
10t capacity electric rubber wheel transfer cart for Malaysia coil handling
10t capacity electric rubber wheel transfer cart for Malaysia coil handling
10t capacity electric rubber wheel transfer cart for Malaysia coil handling
10t capacity electric rubber wheel transfer cart for Malaysia coil handling
10t capacity electric rubber wheel transfer cart for Malaysia coil handling
Specifications
Brand Name :
topleader
Model Number :
BWP-10T
Certification :
CE,ISO
Place of Origin :
China
MOQ :
1set
Price :
US$20000/set
Supply Ability :
300 SET/MONTH
Delivery Time :
45 DAYS OR SO
Packaging Details :
The whole cart is packed by tarp, the parts are packed by the wooden case.
Item :
10t capacity electric rubber wheel transfer cart for Malaysia coil handling
Material :
Q235B
Load capacity :
10000kg
Table size :
4*2, can be customized
Speed :
0-20m/min
Motor :
2*2.2lw
Application :
Aluminum coil plant
Delivery time :
45 days
Cargo transported :
coils
Description

10t capacity electric rubber wheel transfer cart for Malaysia coil handling

Brief of rubber wheel transfer cart

rubber wheel transfer cart is a kind of trackless material handling trolley. It is powered by storage battery. The battery is installed in the handling trolley and we also equip intelligent charger for it. The transfer car is controlled to go forward, backward, turn left, turn right, adjust speed through PLC and speed controller.

10t capacity electric rubber wheel transfer cart for Malaysia coil handling

Composed parts of rubber wheel transfer cart

Cart frame, DC motor, speed reducer, electric control box, storage battery, intelligent charger, driving device, fixed wheels, swivel wheels, braking device, controller, remote-controller, speed controller, lighting alarm and sound alarm, safety bumper, operation device and safe detecting device.

10t capacity electric rubber wheel transfer cart for Malaysia coil handling

Application of rubber wheel transfer cart

Metallurgy, Machinery Fabrication, Auto Makers, Heavy Industry, Light Industry, Mould Maker, Construction Machinery Maker, Shipyard, Port Cargo Yard, Steel Transfer, Mining Transfer, Air and Space as well as Military Industries and so on.

10t capacity electric rubber wheel transfer cart for Malaysia coil handling

Advantages of rubber wheel transfer cart

It can realize double way moving and 360 degree turning.

No damage to the ground surface painting.

No track constraint.

No railway construction limit and maintenance trouble.

Part sale performance

No. Exported countries Product name Product model Quantity Unit
1 Thailand Rail transfer cart KPDZ-16T 2 sets
2 Germany Battery power transfer car KPX-10T 2 sets
3 Syria Battery power transfer car KPX-120T 1 set
4 Syria Battery power transfer car KPX-30T 1 set
5 Turkey Battery power transfer car KPX-40T 3 sets
6 South Africa Battery power transfer car KPX-6T 2 sets
7 Nepal Battery power transfer car KPX-6T 2 sets
8 Singapore Cable power transfer car KPJ-15T 1 set
9 Singapore Cable power transfer car KPJ-10T 1 set
10 Singapore Towed transfer car KP-15T 1 set
11 Mongolia Cable power transfer car KPJ-30T 2 sets
12 Saudia Arabia Cable power transfer car KPX-60T 2 sets
13 Austrilia Battery power transfer car KPX-60T 1 set
14 Singapore Hoist trolley HB-4T 1 set
15 Singapore Hoist trolley HB-15T 2 sets
16 India Battery power transfer car KPX-20T 1 set
17 Singapore Electric turntable 2 sets
18 Mexico cable power transfer car KPJ-60T 1 set
19 Turkey cable power transfer car KPJ-10T 1 set
20 Saudia Arabia Busbar powered transfer car KPC-10T 1 set
In order to protect clients' information, client's company names keep secret

Parameter of rubber wheel transfer cart

Model BWP-10T
Rated Load(t) 10t
Impacted rated load(t) 15
structure of frame steel plates welded beam structure
Thickness of the steel plate 10
Cart weight(t) 5.3
Wheel load(t) 4.6
Ground requirement cement ground
Table size(mm) 3600x2000
Height of the whole cart(mm) 530
Space from the ground(mm) 50
Wheels distance 1500
Axles distance 3100
Turning radius(mm) 3100
Turning type turning while driving without stop
Control method for turning control button
Turning structure mechanical
Wheel diameter Ф300/4
Wheel quality polyurethane wheels
Running speed(m/min) 0-15
Brake principle electric magnetic force
Operation method with wire or no wire
Charger motor's installation installed on cart
Function of charger motor automatic charging
Warning equipment sound and light


Package and shipping

10t capacity electric rubber wheel transfer cart for Malaysia coil handling

The client visit our factory

10t capacity electric rubber wheel transfer cart for Malaysia coil handling

10t capacity electric rubber wheel transfer cart for Malaysia coil handling

About us

Xinxiang New Leader Machinery Manufacturing company has won the great fame by its clients with the excellent design and advanced technology of transfer carts, besides that, it is also believed to be the long cooperate partners by its customers with the perfect after-sale service.

10t capacity electric rubber wheel transfer cart for Malaysia coil handling

10t capacity electric rubber wheel transfer cart for Malaysia coil handling
