5t Capacity Motorized Steerable Transport Platform For Netherlands Machinery Parts Plant
5t Capacity Motorized Steerable Transport Platform For Netherlands Machinery Parts Plant
5t Capacity Motorized Steerable Transport Platform For Netherlands Machinery Parts Plant
5t Capacity Motorized Steerable Transport Platform For Netherlands Machinery Parts Plant
5t Capacity Motorized Steerable Transport Platform For Netherlands Machinery Parts Plant
5t Capacity Motorized Steerable Transport Platform For Netherlands Machinery Parts Plant
5t Capacity Motorized Steerable Transport Platform For Netherlands Machinery Parts Plant
5t Capacity Motorized Steerable Transport Platform For Netherlands Machinery Parts Plant
Specifications
Brand Name :
topleader
Model Number :
BWP-5T
Certification :
CE,ISO
Place of Origin :
China
MOQ :
1set
Price :
US$20000/set
Supply Ability :
300 SET/MONTH
Delivery Time :
45 DAYS OR SO
Packaging Details :
The whole motorized steerable transport platform is packed by tarp, the parts are packed by the wooden case.
Item :
5t Capacity Motorized Steerable Transport Platform For Netherlands Machinery Parts Plant
Material :
Q235B
Load capacity :
5000kg
Table size :
4*2, can be customized
Speed :
0-20m/min
Motor :
2*1lw
Application :
machinery parts plant
Delivery time :
45 days
Cargo transported :
shaft, valve
Description

5t capacity motorized steerable transport platform for Netherlands machinery parts plant

Brief of steerable transport platform

The steerable transport platform is powered by power or diesel generating and it can realize double way moving and turning. The trolley turns around any fixed wheel and turns 360 degree. The turning radius is the trolley length.

5t Capacity Motorized Steerable Transport Platform For Netherlands Machinery Parts Plant

Composed parts of steerable transport platform

Cart frame, DC motor, speed reducer, electric control box, storage battery, intelligent charger, driving device, fixed wheels, swivel wheels, braking device, controller, remote-controller, speed controller, lighting alarm and sound alarm, safety bumper, operation device and safe detecting device.

5t Capacity Motorized Steerable Transport Platform For Netherlands Machinery Parts Plant

Application of steerable transport platform

It is widely used in automobile production, shipbuilding industry, steel and iron transfer and large-size machine equipment transfer and assembly.

5t Capacity Motorized Steerable Transport Platform For Netherlands Machinery Parts Plant

Advantages of steerable transport platform

It can realize double way moving and 360 degree turning.

No damage to the ground surface painting.

No track constraint.

High safety level. Zero emission. Lower Noise. Environmental protection design.

5t Capacity Motorized Steerable Transport Platform For Netherlands Machinery Parts Plant

Part sale performance

No.

Exported countries

Product name

Product model

Quantity

Unit

1

Thailand

Rail transfer cart

KPDZ-16T

2

sets

2

Germany

Battery power transfer car

KPX-10T

2

sets

3

Syria

Battery power transfer car

KPX-120T

1

set

4

Syria

Battery power transfer car

KPX-30T

1

set

5

Turkey

Battery power transfer car

KPX-40T

3

sets

6

South Africa

Battery power transfer car

KPX-6T

2

sets

7

Nepal

Battery power transfer car

KPX-6T

2

sets

8

Singapore

Cable power transfer car

KPJ-15T

1

set

9

Singapore

Cable power transfer car

KPJ-10T

1

set

10

Singapore

Towed transfer car

KP-15T

1

set

11

Mongolia

Cable power transfer car

KPJ-30T

2

sets

12

Saudia Arabia

Cable power transfer car

KPX-60T

2

sets

13

Austrilia

Battery power transfer car

KPX-60T

1

set

14

Singapore

Hoist trolley

HB-4T

1

set

15

Singapore

Hoist trolley

HB-15T

2

sets

16

India

Battery power transfer car

KPX-20T

1

set

17

Singapore

Electric turntable

2

sets

18

Mexico

cable power transfer car

KPJ-60T

1

set

19

Turkey

cable power transfer car

KPJ-10T

1

set

20

Saudia Arabia

Busbar powered transfer car

KPC-10T

1

set

In order to protect clients' information, client's company names keep secret

Parameter of steerable transport platform

Model

BWP-5T

Rated Load(t)

5t

Impacted rated load(t)

7.5

structure of frame

steel plates welded beam structure

Thickness of the steel plate

8

Cart weight(t)

4.3

Wheel load(t)

2.8

Ground requirement

cement ground

Table size(mm)

3000x2000

Height of the whole cart(mm)

450

Space from the ground(mm)

50

Wheels distance

1500

Axles distance

2500

Turning radius(mm)

2500

Turning type

turning while driving without stop

Control method for turning

control button

Turning structure

mechanical

Wheel diameter

Ф300/4

Wheel quality

polyurethane wheels

Running speed(m/min)

0-15

Brake principle

electric magnetic force

Operation method

with wire or no wire

Charger motor's installation

installed on cart

Function of charger motor

automatic charging

Warning equipment

sound and light

Package and Shipping

5t Capacity Motorized Steerable Transport Platform For Netherlands Machinery Parts Plant

The client visit our factory

5t Capacity Motorized Steerable Transport Platform For Netherlands Machinery Parts Plant

5t Capacity Motorized Steerable Transport Platform For Netherlands Machinery Parts Plant

About us

Xinxiang New Leader Machinery Manufacturing Co., Ltd is devoted to manufacture and sell lifting and handling equipment. Our products cover rail transfer car, steerable transfer car, trackless flat cart, bay to bay rail transfer cart, rail wheel, industrial winch, etc.

Our products have a wide application field including metallurgy industry, machinery manufacturing industry, steel mill, mine industry, power industry, mold industry, automobile assembly industry, shipyard industry, etc.
