Specifications
Brand Name :
Topleader
Model Number :
BWP-75T
Certification :
CE,ISO9000
Place of Origin :
China
MOQ :
1 set
Price :
$120000-$150000
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
600 sets/year
Delivery Time :
50 days after your prepayment
Packaging Details :
The whole battery steerable transfer car will be packed by the tarp, the parts will be packed by polywood case.
Product name :
75t Battery Steerable Transfer Car For Heavy Duty Steel Parts Handling In Netherleand Workshop
Power supply :
Storage battery
Material :
steel
Load capacity :
1-100T
Running speed :
0-20m/min
Application :
Factory ,warehouse and working line
Warranty :
1 year
Color :
customized
OEM :
Accepted
Description

75t Battery Steerable Transfer Car For Heavy Duty Steel Parts Handling In Netherleand Workshop


Working Principle of battery steerable transfer car


The 75t Battery Steerable Transfer Car For Heavy Duty Steel Parts Handling In Netherleand Workshop is powered by storage battery. The battery is installed in the trackless transfer car and we also equip intelligent charger for it. The trackless steerable transfer car is controlled to go forward, backward, turn left, turn right, adjust speed through PLC and speed controller.

75t Battery Steerable Transfer Car For Heavy Duty Steel Parts Handling In Netherleand Workshop


Description of battery steerable transfer car


The whole battery steerable transfer car is composed of motor, reducer, electric appliance and wheels. Due to more parts, compared with other carts, it has large size. But it travels flexibly.
The driving wheel and load wheel of trackless transfer car is high strength PU wheel. It is wear-resistance, and has low maintain cost.
The functions of the steerable transfer car including 360 degree turning, go forward and backward, turn left and right, adjust speed button, indicator light, electric indicator light and other control buttons.


75t Battery Steerable Transfer Car For Heavy Duty Steel Parts Handling In Netherleand Workshop


Application of battery steerable transfer car


This kind of battery steerable transfer car is commonly applied in factory or warehouse to transfer heavy materials, such as steel workpiecs, machine parts, etc.


75t Battery Steerable Transfer Car For Heavy Duty Steel Parts Handling In Netherleand Workshop

Technical parameters of battery steerable transfer car

Model BWP-75T
Rated Load(t) 75t
Impacted rated load(t) 95
structure of frame steel plates welded beam structure
Thickness of the steel plate 16
Cart weight(t) 10.5
Wheel load(t) 12
Ground requirement steel plate floor
Table size(mm) 6000x2300
Height of the whole cart(mm) 700
Space from the ground(mm) 50
Wheels distance 1800
Axles distance 5200
Turning radius(mm) 5200
Turning type turning while driving without stop
Control method for turning control button
Turning structure mechanical
Wheel diameter Ф500/6
Wheel quality polyurethane wheels
Running speed(m/min) 0-12
Brake principle electric magnetic force
Operation method with wire or no wire
Charger motor's installation installed on cart
Function of charger motor automatic charging
Warning equipment sound and light lamp

Advantage of battery steerable transfer car

Latest technology based transfer cars systems

Finding application in industrial units for diverting/merging unit loads between multiple lanes

Used in areas like layer pick operations, workstations, transferring loads from multiple palletizer and others

Available in options of single deck or double deck versions

Coming with suitable lift support for addressing multiple receiving and delivery levels

Requires less maintenance

Working features of transfer cars can also be customized as per the specifications provided by customers

75t Battery Steerable Transfer Car For Heavy Duty Steel Parts Handling In Netherleand Workshop


Customer visit in our factory from world wide

75t Battery Steerable Transfer Car For Heavy Duty Steel Parts Handling In Netherleand Workshop

Delivery

75t Battery Steerable Transfer Car For Heavy Duty Steel Parts Handling In Netherleand Workshop
