Specifications
Brand Name :
Topleader
Model Number :
KPD-40T
Certification :
CE,ISO9000
Place of Origin :
China
MOQ :
1 set
Price :
$11000
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
600 sets/year
Delivery Time :
40 days after your prepayment
Packaging Details :
The whole ladle handling transfer cart will be packed by the tarp, the parts will be packed by polywood case.
Product name :
60t Motorized Roadrail Lorry Ladle Handling Transfer Cart For Pakistan Steel Mill
Power supply :
Low voltage 36v
Material :
steel
Load capacity :
1-300T
Running speed :
20m/min
Application :
inplant, production line
Warranty :
1 year
Color :
customized
OEM :
Accepted
Description

60t Motorized Roadrail Lorry Ladle Handling Transfer Cart For Pakistan Steel Mill

Working Principle - Ladle Handling Transfer Cart

The 60t Motorized Roadrail Lorry Ladle Handling Transfer Cart For Pakistan Steel Mill powered by the 36V single-phase (three phase) low voltage rail, which through sliding wire to complete. Ground step-down transformer control cabinet will be single phase (three phase) AC 380V step-down to single-phase (3phase) 36V, sent to the flat car by the rail sliding wire, and then step-up (three phase) single-phase AC 380V by step-up transformers on the transfer cart, provide electricity for the single-phase capacitor motors which used in the cart.

60t Motorized Roadrail Lorry Ladle Handling Transfer Cart For Pakistan Steel Mill

Functions & Advantages - Ladle Handling Transfer Cart

The kind of ladle handling transfer cart is with high level automation.

excellent gear reducer and motor with high quality, assembled together perfectly.

Safe devices are installed in the ladle handling transfer cart.

The turning can be realized for this kind of ladle handling transfer cart, as "s", arc-shaped", "curved rail"

Customization can be supported for the ladle handling transfer cart.

The kind of ladle handling transfer cart is with large capacity and high-quality carbon steel.

It can be used in various occasions as high temperature, easy explosion, ponding, dust, scrap iron...

The hydraulic lifting device can be equipped as per customers' demand.

The V frame can be installed for rounded material as per your need.

DC motor controlled, the speed can be adjusted.

safety, flexibility, stable start, big starting torque, small capacity to the gear reducer.

Long service lifetime for this kind of ladle handling transfer cart.

The running distance of this kinds ladle handling transfer cart is not limited.

This kind of ladle handling transfer cart is battery operated, so only charged fully, can it run freely without limited distance.

60t Motorized Roadrail Lorry Ladle Handling Transfer Cart For Pakistan Steel Mill

Technical Parameters - Ladle Handling Transfer Cart

Model

KPDZ-60T

Rated Load(t)

60

Table size(mm)

5000*2500*650

Wheel Base(mm)

3800

Rail Gauge(mm)

1435

Wheel Diameter(mm)

Ф500

Wheel Quantity(Pcs)

4

Ground Clearance(mm)

50

Running Speed(m/min)

0-20

Motor Power(Kw)

4

Transformer Power(KVA)

10

Transformer Quantity(Set)

1

Running Distance(m)

60

Max Wheel Load(KN)

142.8

Reference Weight(t)

7.6

Recommended Rail Model

P43

Application - Ladle Handling Transfer Cart

60t ladle handling transfer cart is applied in mould factory to transfer injection mold sand mold. The hydraulic lifting device can be added.
For convenience, ladle handling transfer cart is remore control. In order to ensure operator' safety, the V- frame can be added on the platform of the cart.
We can recommend you a suitable auxiliary to you according to the coil dimension, coil weight, etc.


60t Motorized Roadrail Lorry Ladle Handling Transfer Cart For Pakistan Steel Mill
