Custom Heavy-Duty Sliding Line Power Transfer Rail Vehicle for Steel Coil Factory Handling
Custom Heavy-Duty Sliding Line Power Transfer Rail Vehicle for Steel Coil Factory Handling
Custom Heavy-Duty Sliding Line Power Transfer Rail Vehicle for Steel Coil Factory Handling
Custom Heavy-Duty Sliding Line Power Transfer Rail Vehicle for Steel Coil Factory Handling
Custom Heavy-Duty Sliding Line Power Transfer Rail Vehicle for Steel Coil Factory Handling
Custom Heavy-Duty Sliding Line Power Transfer Rail Vehicle for Steel Coil Factory Handling
Custom Heavy-Duty Sliding Line Power Transfer Rail Vehicle for Steel Coil Factory Handling
Custom Heavy-Duty Sliding Line Power Transfer Rail Vehicle for Steel Coil Factory Handling
Specifications
Brand Name :
Topleader
Model Number :
KPC
Certification :
CE,ISO9000
Place of Origin :
China
MOQ :
1 set
Price :
$5000-$12000
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
600 sets/year
Delivery Time :
30-40 days after receive your prepayment
Packaging Details :
The whole transfer rail vehicle will be packed by the tarp, the parts will be packed by polywood case.
Product name :
Custom Heavy-Duty Sliding Line Power Transfer Rail Vehicle for Steel Coil Factory Handling
Power supply :
sliding line
Material :
Q 235 Steel
Load capacity :
1-300T
Running speed :
20m/min
Application :
Factory ,shop,warehouse
Warranty :
1 year
Color :
customized
OEM :
Accepted
Description

Custom Heavy-Duty Sliding Line Power Transfer Rail Vehicle for Steel Coil Factory Handling

Working Principle of the sliding line rail vehicle

KPC Series' busbar powered rail vehicle----its conducts AC380v slinding line directly into the AC electrical control systom of the electric vehicle to let it start, stop, go forward backforward and so on. The vehicle gets power from the slider of the safe sliding line which is moved by the carts running.The operation system is low voltage 36V power.

Custom Heavy-Duty Sliding Line Power Transfer Rail Vehicle for Steel Coil Factory Handling

Sliding line power transfer vehicle introduction

Sliding line power railway vehicles are powered by the busbar. The busbar conducts AC 380V directly into the electrical control system of the transport trolley , then the motor drives the reducer to let the wheel of the trolley start, stop, go forward and backward and so on. The trolley is powered by busbar which is laid in the trench or along the wall.Installation position need to desinged as per client actual application need.

Custom Heavy-Duty Sliding Line Power Transfer Rail Vehicle for Steel Coil Factory Handling
Custom Heavy-Duty Sliding Line Power Transfer Rail Vehicle for Steel Coil Factory Handling Custom Heavy-Duty Sliding Line Power Transfer Rail Vehicle for Steel Coil

Advantage of sliding line power transfer vehicle

1. Contiunous work
2. Special design outlook
3. Convenient installation
4. Low cost and high working efficiency

Custom Heavy-Duty Sliding Line Power Transfer Rail Vehicle for Steel Coil Factory Handling
Custom Heavy-Duty Sliding Line Power Transfer Rail Vehicle for Steel Coil Factory Handling Custom Heavy-Duty Sliding Line Power Transfer Rail Vehicle for Steel Coil

Sliding line power transfer vehicle safe details show

Custom Heavy-Duty Sliding Line Power Transfer Rail Vehicle for Steel Coil Factory Handling
Custom Heavy-Duty Sliding Line Power Transfer Rail Vehicle for Steel Coil Factory Handling Custom Heavy-Duty Sliding Line Power Transfer Rail Vehicle for Steel Coil

Parameter of sliding line power transfer vehicle

Model

KPC-8T

Rated Load(t)

8

Table size(mm)

2000*1500*450

Wheel Base(mm)

1200

Rail Gauge(mm)

1200

Wheel Diameter(mm)

Ф250

Wheel Quantity(Pcs)

4

Ground Clearance(mm)

50

Running Speed(m/min)

25

Motor Power(Kw)

1

Max Wheel Load(KN)

14.4

Reference Weight(t)

3

Recommended Rail Model

P24


Sliding line power transfer vehicle application


Sliding line power railway vehicles are mainly applied in shops , warehouse and inplant for all kinds of cargo handling. It also can be used in the production line and assembly line.

The sliding line vehicle can also applied in high frequency occassions,anti-heat, and anti-explosion workshop,etc.

Custom Heavy-Duty Sliding Line Power Transfer Rail Vehicle for Steel Coil Factory Handling
Custom Heavy-Duty Sliding Line Power Transfer Rail Vehicle for Steel Coil Factory Handling Custom Heavy-Duty Sliding Line Power Transfer Rail Vehicle for Steel Coil
